Cutler-Hammer Series FAZ-D32/3-NA
EATON FAZ-D32/3-NA Current Limiting Miniature Circuit Breaker, 277/480 V AC, 32 A, 10 to 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-D32/3-NA
EATON FAZ-D32/3-NA Current Limiting Miniature Circuit Breaker, 277/480 V AC, 32 A, 10 to 14 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-D32/3-NA
Werner Part #3988493
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-D32/3-NA
Werner Part #3988493
Product Description
EATON Miniature Circuit Breaker, Current Limiting, Series: FAZ-NA, 277/480 V AC, 32 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 10 to 20X Trip, 3 Pole, Toggle Actuator, Screw/Standard Terminal Connection, 18 to 6 AWG, 18 to 10 AWG Wire, DIN Rail Mounting, 40 deg C, 2.97 in W x 2.09 in D x 4.13 in H Dimensions
Attributes
Documents
Applications
Features
Attributes
Connection TypeScrew/Standard Terminal
Country of OriginES
Dimensions2.97 in W x 2.09 in D x 4.13 in H
Enclosure TypeNEMA AB1-1993
FrameK
Frequency Rating50/60 Hz
Interrupt Rating10 to 14 kA
ManufacturerEaton
Mounting TypePanel
Number of Poles3
Phase3
SeriesFAZ-NA
Size of Wire3/0 AWG to 250 kcmil
Temperature Rating40 deg C
Trip Range10 to 20X
Trip TypeThermal Magnetic
TypeCurrent Limiting
Voltage277/480 VAC
Applications
Branch Circuit Device, Circuit Protection, Convenience Receptacle Circuits, Motor Control Circuits, HACR Internal/External Equipment, PLC I/O Points, Computers, Power Supplies, Control Instrumentation, Relays, UPS, Datacenters, IT Space, CI and Hyper Converged, Marine Vessels and Equipment, Generation - Renewable Energy, Alternative Energy, Conventional Energy, Power Conditioners and Industrial Applications
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Suitable for branch circuit device protection
- Thermal magnetic over current protection
- Three levels of short circuit protection, categorized by B, C and D curves
- Trip-free design breaker can not be defeated by holding the handle in the On position
- Captive screws cannot be lost
- Field installable shunt trip and auxiliary switch subsequent mounting
- Contact position indicator (red/green)
- Possibility for sealing the toggle in "On/Off" position
