Cutler-Hammer Series FAZ-C3/2-NA
EATON FAZ-C3/2-NA Current Limiting Miniature Circuit Breaker, 277/480 V, 3 A, 14 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-C3/2-NA
EATON FAZ-C3/2-NA Current Limiting Miniature Circuit Breaker, 277/480 V, 3 A, 14 kA Interrupt, 2 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-C3/2-NA
Werner Part #3988461
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-C3/2-NA
Werner Part #3988461
Product Description
EATON Miniature Circuit Breaker, Current Limiting, Series: FAZ-NA, 277/480 V, 3 A, 50/60 Hz Frequency, 14 kA Interrupt, 40A Frame, Thermal Magnetic Trip, 5 to 10 A Trip, 2 Pole, Toggle Actuator, Screw/Standard Terminal Connection, 18 to 6 AWG, 18 to 10 AWG Wire, DIN Rail Mounting, 40 deg C, 1.4 x 2.97 x 4.13 in Dimensions
Attributes
Documents
Applications
Features
Attributes
Connection TypeScrew/Standard Terminal
Country of OriginES
Dimensions1.4 x 2.97 x 4.13 in
Frame40A
Frequency Rating50/60 Hz
Interrupt Rating14 kA
ManufacturerEaton
Mounting TypeBolted-On
Number of Poles2
Phase1
SeriesFAZ-NA
Size of Wire6 to 1/0 AWG
Temperature Rating40 deg C
Trip Range5 to 10 A
Trip TypeThermal Magnetic
TypeCurrent Limiting
Voltage277/480 VAC
Applications
Datacenters, IT Space, CI and Hyper Converged, Branch Circuit Device Protection, Generation - Conventional Energy, Renewable Energy, Alternative Energy, Marine Vessels and Equipment and Industrial Applications
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Suitable for branch circuit device protection
- Thermal magnetic over current protection
- Three levels of short circuit protection, categorized by B, C and D curves
- Trip-free design breaker can not be defeated by holding the handle in the On position
- Captive screws cannot be lost
- Field installable shunt trip and auxiliary switch subsequent mounting
- Contact position indicator (red/green)
- Possibility for sealing the toggle in "On/Off" position
