Cutler-Hammer Series FAZ-C25/2-NA
EATON FAZ-C25/2-NA Current Limiting Miniature Circuit Breaker, 277/480 V, 25 A, 14 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-C25/2-NA
EATON FAZ-C25/2-NA Current Limiting Miniature Circuit Breaker, 277/480 V, 25 A, 14 kA Interrupt, 2 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-C25/2-NA
Werner Part #3981038
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-C25/2-NA
Werner Part #3981038
Product Description
EATON Miniature Circuit Breaker, Current Limiting, Series: FAZ-NA, 277/480 V, 25 A, 50/60 Hz Frequency, 14 kA Interrupt, 40A Frame, Thermal Magnetic Trip, 2 Pole, Screw Connection, 18 to 10 AWG, 18 to 6 AWG Wire, DIN Rail Mounting, -25 to 75 deg C, 1.4 x 2.97 x 4.13 in Dimensions
Attributes
Documents
Applications
Features
Attributes
Actuator TypeHandle
Connection TypeScrew
Country of OriginES
Dimensions1.4 x 2.97 x 4.13 in
Enclosure TypeNEMA AB1-1993
Frame40A
Frequency Rating50/60 Hz
Interrupt Rating14 kA
ManufacturerEaton
Mounting TypePanel
Number of Poles2
Phase3
SeriesFAZ-NA
Size of Wire18 to 10 AWG, 18 to 6 AWG
Temperature Rating-25 to 75 deg C
Trip TypeThermal Magnetic
TypeCurrent Limiting
Type / StyleType FAZ-NA
Voltage277/480 VAC
Applications
Renewable Energy and Alternative Energy Generation, Marine Vessels and Equipment, Conventional Energy, Datacenters - IT Space, CI and Hyper Converged Data Centers, Branch Circuit Device Protection and Industrial Applications
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Trip-free design breaker can not be defeated by holding the handle in the On position
- Captive screws cannot be lost
- SWD (switching duty) suitable for switching fluorescent lighting loads
- Field installable shunt trip and auxiliary switch subsequent mounting
- Contact position indicator (red/green)
- Possibility for sealing the toggle in "On/Off" position
