Cutler-Hammer Series FAZ-C20/2-NA
EATON FAZ-C20/2-NA Standard Current Limiting Supplementary Protector, 277/480 V, 20 A, 14 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-C20/2-NA
EATON FAZ-C20/2-NA Standard Current Limiting Supplementary Protector, 277/480 V, 20 A, 14 kA Interrupt, 2 Poles, Thermal Magnetic TripIn Stock: 2more info
|
BrandCutler-Hammer Series
MFG #FAZ-C20/2-NA
Werner Part #3981037
UPC786689005160
In Stock: 2more info
|
BrandCutler-Hammer Series
MFG #FAZ-C20/2-NA
Werner Part #3981037
UPC786689005160
Product Description
EATON Supplementary Protector, Standard Current Limiting, Series: FAZ, 277/480 V, 20 A, 50/60 Hz Frequency, 14 kA Interrupt, Thermal Magnetic Trip, 2 Pole, Handle Actuator, 18 to 10 AWG, 18 to 6 AWG Wire, DIN Rail Mounting, -25 to 75 deg C, 1.4 x 2.97 x 4.13 in Dimensions
Attributes
Documents
Applications
Features
Attributes
Actuator TypeHandle
Country of OriginES
Dimensions1.4 x 2.97 x 4.13 in
Frequency Rating50/60 Hz
Interrupt Rating14 kA
ManufacturerEaton
Number of Poles2
SeriesFAZ
Size of Wire18 to 10 AWG, 18 to 6 AWG
Suitable For Use WithPower Break II SSD, SHD, SSF, SHE Frame Insulated Case Circuit Breaker
Temperature Rating-25 to 75 deg C
Trip TypeThermal Magnetic
TypeStandard Current Limiting
Type / StyleType FAZ-NA Standard Current Limiting
Voltage277/480 VAC
Applications
Datacenters - IT Space, CI and Hyper Converged Data Centers, Conventional Energy Generation, Renewable Energy and Alternative Energy Generation, Marine Vessels and Equipment and Circuit Protection Applications
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Thermal magnetic over current protection
- Three levels of short circuit protection, categorized by B, C and D curves
- Trip-free design breaker can not be defeated by holding the handle in the On position
- A color coded red/green indicator provides immediate visual indication of device status (green for Off, red for On) and isolation function
- Power to the circuit breakers can be fed from the line or load side
- Easy installation on DIN rail
- To save installation time, bus connectors and feeder terminal facilitate mounting and wiring of multiple miniature circuit breaker arrays in control panel assemblies
