Cutler-Hammer Series FAZ-B32/3
EATON FAZ-B32/3 Standard Current Limiting Supplementary Protector, 480Y/277 V AC, 32 A, 15 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-B32/3
EATON FAZ-B32/3 Standard Current Limiting Supplementary Protector, 480Y/277 V AC, 32 A, 15 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-B32/3
Werner Part #3966781
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #FAZ-B32/3
Werner Part #3966781
Product Description
EATON Supplementary Protector, Standard Current Limiting, Series: FAZ, 480Y/277 V AC, 32 A, 50/60 Hz Frequency, 15 kA Interrupt, Thermal Magnetic Trip, 3 Pole, Handle Actuator, 18 to 4 AWG, 18 to 8 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -40 to 75 deg C, 2.07 in L Dimensions, Nylon
Attributes
Documents
Applications
Features
Attributes
Actuator TypeHandle
Country of OriginRO
Dimensions2.07 in L
Enclosure TypeIP20
Frequency Rating50/60 Hz
Interrupt Rating15 kA
ManufacturerEaton
MaterialNylon
Number of Poles3
Package TypeEACH
SeriesFAZ
Size of Wire18 to 4 AWG, 18 to 8 AWG
Suitable For Use WithFused Disconnect Switches
Temperature Rating-40 to 75 deg C
Trip TypeThermal Magnetic
TypeStandard Current Limiting
Type / StyleType FAZ Standard Current Limiting
Voltage480Y/277 VAC
Documents
Applications
Circuit Protection, Control Circuits, Lighting, Business Equipment, Appliances, Conventional Energy Generation, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment and Industrial Applications
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Thermal magnetic over current protection
- Trip-free design breaker can not be defeated by holding the handle in the On position
- A color coded red/green indicator provides immediate visual indication of device status (green for Off, red for On) and isolation function
- Power to the circuit breakers can be fed from the line or load side
- Captive screws cannot be lost
- Small modular width of the device and accessories saves space in the panel or equipment, which can lead to cost savings
- B curve designed for resistive or slightly inductive loads
- For international and domestic use
- Suitable for applications where protection against low level short circuit faults in control wiring is desired
