Cutler-Hammer Series EGS3020FFB
EATON EGS3020FFB G Series Type EGS Molded Case Circuit Breaker, 347/600Y V AC, 20 A, 22/35/85 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series EGS3020FFB
EATON EGS3020FFB G Series Type EGS Molded Case Circuit Breaker, 347/600Y V AC, 20 A, 22/35/85 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Molded Case Circuit Breaker, Type EGS, Series: G Series, 347/600Y V AC, 20 A, 50/60 Hz Frequency, 22/35/85 kA Interrupt, EG Frame, Thermal Magnetic Trip, 3 Pole, 3 ph, Line/Load Connection, NEMA AB1-1993 Enclosure, Bolted-On Mounting, 40 deg C, 2.99 in L x 3 in W x 5.5 in H Dimensions
Attributes
Documents
Applications
Included
Features
Attributes
Actuator TypeToggle
Connection TypeLine/Load
Country of OriginDO
Dimensions2.99 in L x 3 in W x 5.5 in H
Enclosure TypeNEMA AB1-1993
FrameEG
Frequency Rating50/60 Hz
Interrupt Rating22/35/85 kA
ManufacturerEaton
Mounting TypeDIN Rail
Number of Poles3
Phase3
SeriesG Series
Size of Wire18 to 6 AWG, 18 to 10 AWG
Temperature Rating40 deg C
Trip Range10 to 20
Trip TypeThermal Magnetic
TypeType EGS
Type / StyleType EGS
Voltage347/600Y VAC
Documents
Applications
Panelboard, Switchboard, Motor Control Center and Busway Applications
Included
Frame, Trip Unit, Standard Terminals and Mounting Hardware
Features
- Compact design-frees up panel space
- Common field fit internal accessories make installation and custom configuration easy
- Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
- Patented contact design features high speed "blow open" action, resulting in superior performance
- 85 kA at 240 VAC, 35 kA at 480 VAC, 22 kA at 600Y/347 VAC interrupt rating
