Cutler-Hammer Series ED3150
EATON ED3150 C Series Type ED Molded Case Circuit Breaker, 240 V AC/125 V DC, 150 A, 65 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series ED3150
EATON ED3150 C Series Type ED Molded Case Circuit Breaker, 240 V AC/125 V DC, 150 A, 65 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #ED3150
Werner Part #574171
UPC786679455265
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #ED3150
Werner Part #574171
UPC786679455265
Product Description
EATON Molded Case Circuit Breaker, Type ED, Series: C Series, 240 V AC/125 V DC, 150 A, 50/60 Hz Frequency, 65 kA Interrupt, F Frame, Thermal Magnetic Trip, 3 Pole, 3 ph, Handle Actuator, Load Connection, NEMA AB1-1993 Enclosure, Panel Mounting, 40 deg C, 3.38 in L x 4.13 in W x 4.13 in H Dimensions
Attributes
Documents
Applications
Features
Attributes
Actuator TypeHandle
Connection TypeLoad
Country of OriginDO
Dimensions3.38 in L x 4.13 in W x 4.13 in H
Enclosure TypeNEMA AB1-1993
FrameF
Frequency Rating50/60 Hz
Interrupt Rating65 kA
ManufacturerEaton
Mounting TypePanel
Number of Poles3
Package Height5 in
Package Length3.38 in
Package TypeEACH
Package Weight4.5 lb
Package Width4.13 in
Phase3
SeriesC Series
Size of Wire14 to 10 AWG, 12 to 10 AWG
Temperature Rating40 deg C
Trip TypeThermal Magnetic
TypeType ED
Type / StyleType ED
Voltage240 VAC, 125 VDC
Documents
Applications
Panelboard, Switchboard, Motor Control Center and Busway Applications
Features
- Patented contact design features high speed "blow open" action, resulting in superior performance
- Suitable for reverse feed application
- 65 kA at 240 VAC interrupt rating
