Cutler-Hammer Series ED2125L
EATON ED2125L C Series Type ED Molded Case Circuit Breaker, 240 V AC/125 V DC, 125 A, 65 kAIC at 240 VAC Interrupt, 2 Poles, Thermal Magnetic Trip
Cutler-Hammer Series ED2125L
EATON ED2125L C Series Type ED Molded Case Circuit Breaker, 240 V AC/125 V DC, 125 A, 65 kAIC at 240 VAC Interrupt, 2 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #ED2125L
Werner Part #3957091
UPC786679454244
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #ED2125L
Werner Part #3957091
UPC786679454244
Product Description
EATON Molded Case Circuit Breaker, Type ED, Series: C Series, 240 V AC/125 V DC, 125 A, 50/60 Hz, 65 kAIC at 240 VAC Interrupt, F Frame, Thermal Magnetic Trip, 2 Pole, Handle Actuator, Line/Load, 40 deg C, 3.38 x 2.75 x 2.75 in
Attributes
Documents
Applications
Warranty
Features
Attributes
Actuator TypeHandle
ColorBlack
Connection TypeLine/Load
Country of OriginDO
Dimensions3.38 x 2.75 x 2.75 in
FinishTin Plated
FrameF
Frequency Rating50/60 Hz
Interrupt Rating65 kAIC at 240 VAC
ManufacturerEaton
MaterialAluminum/Thermoplastic
Number of Poles2
Package TypeEACH
Primary Connection/Pole1
Secondary Connection/Pole5
SeriesC Series
Short Circuit Current Rating10 kA
Size of Wire6 AWG to 350 kcmil
Temperature Rating40 deg C
Trip TypeThermal Magnetic
TypeType ED
Type / StyleType ED
Voltage240 VAC, 125 VDC
Documents
Applications
Panelboard, Switchboard, Motor Control Center and Busway Applications
Warranty
1 year
Features
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Suitable for reverse feed applications
- 65 kA at 240 VAC interrupt rating
