Cutler-Hammer Series CHFEP130
EATON CHFEP130 Type CHF Molded Case Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 1 Poles, Thermal Magnetic Trip
Cutler-Hammer Series CHFEP130
EATON CHFEP130 Type CHF Molded Case Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 1 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #CHFEP130
Werner Part #4012930
UPC786685628011
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #CHFEP130
Werner Part #4012930
UPC786685628011
Product Description
EATON Molded Case Circuit Breaker, Type CHF, 120/240 VAC, 30 A, 10 kA Interrupt, Thermal Magnetic Trip, 1 Pole, 14 to 4 AWG Wire, 6 in L x 3-1/2 in W x 1-1/4 in H Dimensions
Attributes
Documents
Applications
Features
Attributes
Connection TypeLine/Load
Country of OriginDO
Dimensions6 in L x 3-1/2 in W x 1-1/4 in H
Enclosure TypeNEMA AB1-1993
FrameL
Frequency Rating50/60 Hz
Interrupt Rating10 kA
ManufacturerEaton
Mounting TypeBolted-On
Number of Poles1
Package Height6.5 IN
Package Length7.25 in
Package TypeEACH
Package Weight2.79 lb
Package Width6.75 in
Phase3
SeriesC Series
Size of Wire4/0 AWG to 600 kcmil
Temperature Rating40 deg C
Trip TypeThermal Magnetic
TypeType CHF
Type / StyleType CHF
Voltage120/240 VAC
Documents
Applications
Conventional Energy Generation, Renewable Energy and Alternative Energy Generation, Marine Vessels and Equipment, Commercial and Telecom/Data, Datacenters - IT Space, CI and Hyper Converged Applications
Features
- The "panel neutral" conductor connects to the neutral bar, even though the neutral is not included in a 240 VAC load circuit, this connection is necessary to supply a 120 VAC power source to the ground fault sensing circuit
- Add the AFCI tester and circuit analyzer to verify proper wiring in a circuit, it's the only tester with GFI function and line neutral test feature
