EATON AH460P7W
EATON Arrow Hart Eaton Wiring Devices AH460P7W 3-Phase Watertight Arrow Hart Pin and Sleeve Plug, 480 V AC, 60 A, 3 Poles, 4 Wires, Red
EATON AH460P7W
EATON Arrow Hart Eaton Wiring Devices AH460P7W 3-Phase Watertight Arrow Hart Pin and Sleeve Plug, 480 V AC, 60 A, 3 Poles, 4 Wires, RedOut of Stockmore info
|
BrandEATON
MFG #AH460P7W
Werner Part #4036814
UPC032664732478
Out of Stockmore info
|
BrandEATON
MFG #AH460P7W
Werner Part #4036814
UPC032664732478
Product Description
EATON Arrow Hart Eaton Wiring Devices Arrow Hart Pin and Sleeve Plug, 3-Phase Watertight, 480 V AC, 60 A, 15 hp, 3 Pole, 4 Wires, Industrial Grade, IP67/IP69K Enclosure, 86 deg F, Screw Terminal, Thermoplastic, Red, 4.45 in Dia x 9.26 in L Dimensions
Attributes
Documents
Applications
Features
Specifications
Attributes
ColorRed
Country of OriginChina
Dimensions4.45 in Dia x 9.26 in L
Enclosure TypeIP67/IP69K
GradeIndustrial
Horsepower15 hp
ManufacturerEaton
MaterialThermoplastic
Number of Poles3
Number of Wires4
Package Height5.13 in
Package Length11.5 IN
Package TypeEACH
Package Volume302.05 cu-in
Package Weight1.96 lb
Package Width5.12 in
Temperature Rating86 deg F
Terminal TypeScrew
Type3-Phase Watertight
Type / Style3-Phase Watertight
Voltage Rating480 V AC
Documents
Applications
Industrial Applications
Features
- Nickel plated pins and contacts offer long-life corrosion protection
- Plugs have a lockout hole for added safety
- Individual silicone sealing grommets with cord diameter indication provide for faster and easier assembly
- Tri-combo hardware for convenience
- Threaded NPT cable entry provides an efficient means of attaching flexible conduit or wire mesh grips
- Inlet and receptacle mounting footprint and blind holes provide interchangeability with major brands
- Impact-resistant thermoplastic insulation
- Cable mounting
- 3000 vac dielectric voltage
- Maximum 86 deg f (30 deg C) after 50 cycles of overload at 150% of rated current
- 0.66 to 1.5 in Dia cord
- 1-1/2 in NPT threaded entry
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|IEC 60309
