Cutler-Hammer Series GHB3040

Cutler-Hammer GHB3040 Type GHB Molded Case Circuit Breaker With Non-Interchangeable Trip Unit, 277/480 V AC/125/250 V DC, 40 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer GHB3040 Type GHB Molded Case Circuit Breaker With Non-Interchangeable Trip Unit, 277/480 V AC/125/250 V DC, 40 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip

Cutler-Hammer Series GHB3040

Cutler-Hammer GHB3040 Type GHB Molded Case Circuit Breaker With Non-Interchangeable Trip Unit, 277/480 V AC/125/250 V DC, 40 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
In Stock: 8more info
|

BrandCutler-Hammer Series

MFG #GHB3040

Werner Part #24748

UPC786679911280

In Stock: 8more info
|

BrandCutler-Hammer Series

MFG #GHB3040

Werner Part #24748

UPC786679911280

Product Description

Cutler-Hammer Molded Case Circuit Breaker, Series: Type GHB, 277/480 V AC/125/250 V DC, 40 A, 50/60 Hz Frequency, 14 kA Interrupt, G Frame, Thermal Magnetic Trip, 3 Pole, 3 ph, Line/Load Connection, 10 to 1/0 AWG Wire, NEMA 4 Enclosure, Bolted-On Mounting, 40 deg C, 6.6 in L x 3.8 in W x 4 in H Dimensions
Attributes
ColorBlack
Connection TypeLine/Load
Country of OriginDominican Republic
Dimensions6.6 in L x 3.8 in W x 4 in H
Enclosure TypeNEMA 4
FrameG
Frequency Rating50/60 Hz
Interrupt Rating14 kA
ManufacturerEaton
MaterialThermoplastic
Number of Poles3
Package Weight1.75 lb
Phase3
Primary Connection/Pole1
Secondary Connection/Pole6
SeriesType GHB
Short Circuit Current Rating10 kA
Size of Wire14 to 2/0 AWG Cu, 8 to 2/0 AWG Al Line, 14 to 4 AWG Cu, 8 to 4 AWG Al Load
Temperature Rating40 deg C
Trip TypeThermal Magnetic
TypeStandard
Type / StyleMolded case circuit breaker
Voltage277/480 VAC/125/250 VDC
