Color-Keyed 60116-TB
Color-Keyed 60116-TB 1-Hole Non-Insulated Compression Lug, 2 AWG Aluminum/Copper Conductor, Die Code: 42H, 1/4 in Stud, Aluminum
Color-Keyed 60116-TB
Color-Keyed 60116-TB 1-Hole Non-Insulated Compression Lug, 2 AWG Aluminum/Copper Conductor, Die Code: 42H, 1/4 in Stud, AluminumNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Color-Keyed Compression Lug, 1-Hole Non-Insulated, Aluminum/Copper Conductor, 2 AWG Conductor, Die Code: 42H, 35 kV, 1/4 in Stud, 0.75 in L x 0.72 in W x 0.19 in THK Tongue, 1.91 in Overall Length, Blind End/Long Barrel, 0.51 in Dia Barrel, Specifications: Tin Plated, 90 deg C, Aluminum, Pink
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.51 in Dia
Barrel TypeBlind End/Long
ColorPink
Conductor size2 AWG
Conductor TypeAluminum/Copper
Country of OriginMX
Die Code42H
ManufacturerABB
MaterialAluminum
Overall Length1.91 in
Package Length3.3 in
Package TypeEACH
Package Volume17.28 cu-in
Package Weight0.03 lb
Package Width2.8 in
Stud Size1/4 in
Temperature Rating90 deg C
Tongue Size0.75 in L x 0.72 in W x 0.19 in THK
Type1-Hole Non-Insulated
Type / Style1-Hole
Voltage Rating35 kV
Documents
Features
- For 90 deg C certified to 600 VAC and recommended up to 35 kVAC applications
- Easily matched to the correct Color-Keyed installing die for positive compressions
- Hardened steel dies compress connector around cable, changing round strands to polygonal shapes and cold flowing strands and connector into a solid, homogenous mass
- Long compression areas ensure complete contact
- Multiple compressions prevent creep of aluminum conductors
- Filled with high temperature oxide inhibiting compound
- Electro-tin plating prevents electrolytic corrosion of copper to ensure lowest contact resistance
- High conductivity wrought aluminum construction
Specifications
Tin Plated
