Color-Keyed 54930BE
Color-Keyed 54930BE 54900 1-Hole Non-Insulated Compression Lug, 8 AWG Copper/Stranded Conductor, Die Code: 21, 1/4 in Stud, Copper
Color-Keyed 54930BE
Color-Keyed 54930BE 54900 1-Hole Non-Insulated Compression Lug, 8 AWG Copper/Stranded Conductor, Die Code: 21, 1/4 in Stud, CopperIn Stock: 51more info
|
In Stock: 51more info
|
Product Description
Color-Keyed Compression Lug, 1-Hole Non-Insulated, Series: 54900, Copper/Stranded Conductor, 8 AWG Conductor, Die Code: 21, 35 kV, 1/4 in Stud, Straight Tongue, 0.65 in L x 0.42 in W x 0.08 in THK Tongue, 1.65 in Overall Length, Blind End/Long/Straight Barrel, 0.26 in Dia Barrel, Specifications: 1/4 in Center of Hole to Tongue End, Tin Plated, 0.281 in Mounting Hole, Copper, Red
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.26 in Dia
Barrel TypeBlind End/Long/Straight
ColorRed
Conductor size8 AWG
Conductor TypeCopper/Stranded
Country of OriginMX
Die Code21
ManufacturerABB
MaterialCopper
Mounting Hole Type0.281 in
Overall Length1.65 in
Package TypeEACH
Series54900
Stud Size1/4 in
Tongue Size0.65 in L x 0.42 in W x 0.08 in THK
Tongue TypeStraight
Type1-Hole Non-Insulated
Type / Style1-Hole
Voltage Rating35 kV
Documents
Applications
For providing a high degree of reliability in electrical wiring
Features
- Connectors have colored bands or colored dots that correspond to color markings on the dies
- Color-Keyed connectors are banded by colored stripes or engraving to indicate location of die on connector for compression
- Connection by compression
- High quality connection at a low installed cost
- High conductivity wrought copper construction
- 1/4 in hole center to end
- Tin plated finish
Specifications
1/4 in Center of Hole to Tongue End, Tin Plated
