Carlon NS10106
Carlon NS10106 Nema Enclosure, 10 in W x 6 in D 10 in H, NEMA 1/2/3/3S/3X/3SX/4/4X/12 NEMA Rating, Polycarbonate
Carlon NS10106
Carlon NS10106 Nema Enclosure, 10 in W x 6 in D 10 in H, NEMA 1/2/3/3S/3X/3SX/4/4X/12 NEMA Rating, PolycarbonateNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Carlon NS10106 Nema Enclosure, 10 in Width, 6 in Depth, 10 in Height, NEMA 1/2/3/3S/3X/3SX/4/4X/12 NEMA Rating, Screw-On Cover, 8.88 in W x 8.75 in H Panel, Lock: Latch, Wall Mounting, -30 to 230 deg F, Polycarbonate, Gray
Attributes
Documents
Applications
Features
Included
Specifications
Attributes
ColorGray
Country of OriginUS
Cover TypeScrew-On
ManufacturerABB
MaterialPolycarbonate
Mounting TypeWall
NEMA RatingNEMA 1/2/3/3S/3X/3SX/4/4X/12
Package Length0.01 in
Package TypeEACH
Package Weight5.09 lb
Package Width0.01 in
Panel Size8.88 in W x 8.75 in H
Size8.88 in W x 8.75 in H
Temperature Rating-30 to 230 deg F
Type / StyleCircuit Safe NEMA Enclosures
Documents
Applications
Septic and Pump Controls, Wireless System Component Protection, Security System Controls, Marina and Sea Side Installations
Features
- 100% non-metallic construction, including hinges
- Sturdy SS latches install without penetration of the enclosure base
- All cover screws are captive
- Panel suspension system allows the installation of panels at any depth, including stacking of multiple panels
- Non-metallic mounting rails for easy installation
- Less than half the weight of metal enclosures, 25% lighter than fiberglass, easier to handle and less expensive to ship
- 380 V/mil dielectric strength, 3 at 60 Hz, 2.96 at 106 Hz dielectric constant
Included
Body, Lid and Mounting Rail Kit
Specifications
Latch
