Brad 803001A09M100
Brad Micro-Change Woodhead 803001A09M100 120065 Single Ended Cordset, M12 90 deg Female x Straight Pigtail Connector, 10 m L Cable, 3 Poles, Single Keyway
Brad 803001A09M100
Brad Micro-Change Woodhead 803001A09M100 120065 Single Ended Cordset, M12 90 deg Female x Straight Pigtail Connector, 10 m L Cable, 3 Poles, Single KeywayNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Brad Micro-Change Woodhead Cordset, Single Ended, Series: 120065, 90 deg Female x Straight Pigtail Connector, M12 Connector, PUR Connector, 22 AWG E152210 Cable, 10 m Cable Length, PVC Cable, 3 Pole, Single Keyway, 250 V AC/DC, 4 A
Attributes
Documents
Applications
Features
Attributes
Cable Length10 m
Cable MaterialPVC
Connector MaterialPUR
Connector SizeM12
Connector Type90 deg Female x Straight Pigtail
Country of OriginUS
KeywaySingle
LengthCable: 10 m
ManufacturerMolex
NEMA RatingIP67
Number of Poles3
Package TypeEACH
Return & Cancellation PolicyNonreturnable/Noncancellable
Series120065
Type / StyleSingle Ended
Type of Cable22 AWG E152210
Documents
Applications
For class 2 power and network circuit applications
Features
- This sensor cordset is designed to offer a quick alternative to hardwiring sensors and switches
- M12 design meets IEC specifications
- Industry standard interface compatible with a wide array of sensors and switches
- Provides a longer lasting, high performance electrical contact
- Prevents the coupler from loosening even under extreme vibration
- Harsh duty receptacle
