Bussmann Series LP-CC-2
Bussmann Low-Peak LP-CC-2 Current Limiting Time Delay Fuse, 2 A, 600 V AC/300 V DC, 200 kA Interrupt, CC Class, Cylindrical Body
Bussmann Series LP-CC-2
Bussmann Low-Peak LP-CC-2 Current Limiting Time Delay Fuse, 2 A, 600 V AC/300 V DC, 200 kA Interrupt, CC Class, Cylindrical BodyIn Stock: 75more info
|
BrandBussmann Series
MFG #LP-CC-2
Werner Part #22614
UPC051712180269
In Stock: 75more info
|
BrandBussmann Series
MFG #LP-CC-2
Werner Part #22614
UPC051712180269
Product Description
Bussmann Low-Peak Time Delay Fuse, Current Limiting, Series: LP-CC, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 2 A, 600 V AC/300 V DC, 200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Melamine, Yellow, 13/32 in Dia x 1-1/2 in L Body Size
Attributes
Documents
Applications
Features
Attributes
Body Size13/32 in Dia x 1-1/2 in L
Body TypeCylindrical
ClassCC
ColorYellow
Country of OriginSri Lanka
ElementDual
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating200 kA
ManufacturerEaton
MaterialMelamine
Mounting TypeHolder
Package Height1.5 in
Package Length1.5 in
Package TypeEACH
Package Weight0.15 lb
Package Width0.41 in
Rejection/Non-RejectionRejection
Response Time12 s at 200%
SeriesLP-CC
Terminal TypeFerrule
Type / StyleDelay Fuse
Voltage Rating600 V AC/300 V DC
Applications
Branch Circuits, Specialized Circuits, Industrial Control and Street Lighting (Isolated, In-Line Fuse Holder) Applications, Safety and Security Systems
Features
- Time delay coupled with Class CC current limiting response provides close sizing on small motor and relay circuits, and maximum component short circuit current rating protection
- 200 kA interrupting rating provides high ratings for control circuit locations
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
- Inventory consolidation of 13/32 x 1-1/2 in supplementary fuses reduces SKU investment and minimizes potential for misapplying fuse
- Selective co-ordination ratio of 2:1 (within Low-Peak fuse family) prevents electrical shutdowns from extending beyond the failed circuit
- Finger-safe design with the Bussmann series Class CF CUBE Fuse
