BURNDY YA30A6
BURNDY HYLUG YA30A6 YA-A 1-Hole Dual Rated Non-Insulated Compression Lug, 300 kcmil Aluminum/Copper Conductor, Die Code: 470, 3/8 in Stud, Aluminum
BURNDY YA30A6
BURNDY HYLUG YA30A6 YA-A 1-Hole Dual Rated Non-Insulated Compression Lug, 300 kcmil Aluminum/Copper Conductor, Die Code: 470, 3/8 in Stud, AluminumNon-stock product. Available to order - lead time may vary.
BrandBURNDY
MFG #YA30A6
Werner Part #3826974
UPC781810755518
Non-stock product. Available to order - lead time may vary.
BrandBURNDY
MFG #YA30A6
Werner Part #3826974
UPC781810755518
Product Description
BURNDY HYLUG Compression Lug, 1-Hole Dual Rated Non-Insulated, Series: YA-A, Aluminum/Copper Conductor, 300 kcmil Conductor, Die Code: 470, 600 V AC to 35 kV, 3/8 in Stud, Standard Straight Tongue, 1.37 in L x 1.38 in W x 0.36 in THK Tongue, 3.9 in Overall Length, Chamfered Barrel, 1.53 in L Barrel, 1-3/4 in L Wire Strip, 90 deg C, Aluminum, Blue
Attributes
Documents
Features
Specifications
Attributes
Barrel Size1.53 in L
Barrel TypeChamfered
ColorBlue
Conductor size300 kcmil
Conductor TypeAluminum/Copper
Country of OriginMX
Die Code470
ManufacturerHubbell
MaterialAluminum
Overall Length3.9 in
Package Length0 in
Package TypeEACH
Package Width0 in
SeriesYA-A
Stud Size3/8 in
Temperature Rating90 deg C
Tongue Size1.37 in L x 1.38 in W x 0.36 in THK
Tongue TypeStandard Straight
Type1-Hole Dual Rated Non-Insulated
Type / Style1-Hole Dual Rated Non-Insulated
Voltage Rating600 V AC to 35 kV
Documents
Features
- Barrel is designed with an internal chamfer at the wire entry to ensure smooth insertion of the wire, preventing possible damage of the wire strands during insertion
- Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive elements
- Connectors are clearly marked with wire size, die index, color code, and crimp location bands
- Factory pre-filled with PENETROX Type A13 oxide inhibitor
- Color coded end caps are factory inserted in the barrels to match the die color code and prevent foreign materials from entering the barrel
- Aluminum oxidation is not easily detected but causes resistance in a connection, it is imperative the proper preparation takes place prior to making an aluminum-to-aluminum connection
Specifications
1-3/4 in L Wire Strip
