BURNDY KPA34
BURNDY SCRULUG KPA34 Cable Terminal Lug, 4/0 AWG to 500 kcmil Copper Conductor, 1/2 in Stud, 1 Bolt Holes, Copper Alloy
BURNDY KPA34
BURNDY SCRULUG KPA34 Cable Terminal Lug, 4/0 AWG to 500 kcmil Copper Conductor, 1/2 in Stud, 1 Bolt Holes, Copper AlloyIn Stock: 12more info
|
In Stock: 12more info
|
Product Description
BURNDY SCRULUG Cable Terminal Lug, Series: KPA, Copper Conductor, 4/0 AWG to 500 kcmil Conductor, 1/2 in Stud, 1 Bolt Holes, 1.5 in W x 0.2 in THK Tongue, Straight Tongue, Specifications: Hex Socket, 375 in-lb Installation Torque, (1) Screw, Copper Alloy, Electro-Zinc Plated, 3.14 in L x 2.44 in H
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size4/0 AWG to 500 kcmil
Conductor TypeCopper
Country of OriginUS
Dimensions3.14 in L x 2.44 in H
FinishElectro-Zinc Plated
ManufacturerHubbell
MaterialCopper Alloy
Number of Bolt Holes1
Package Height2.44 in
Package Length3.32 in
Package TypeEACH
Package Weight0.68 lb
Package Width1.38 in
SeriesKPA
Stud Size1/2 in
Tongue Size1.5 in W x 0.2 in THK
Tongue TypeStraight
Documents
Applications
For joining a wide range of cable to equipment pads or terminal blocks, especially good in light industrial
Features
- Tongue and body are 1-piece design, pressure bar equalizes pressure over the conductor and prevents the screw from cutting into the cable
Specifications
Hex Socket, 375 in-lb Installation Torque, (1) Screw
