Appleton WSR6352
Appleton WSR6352 Fused Grounding Style 2 Interlocked Receptacle With Enclosed Disconnect Switch, 600 V AC/250 V DC, 60 A, 4 Poles, 3 Wires
Appleton WSR6352
Appleton WSR6352 Fused Grounding Style 2 Interlocked Receptacle With Enclosed Disconnect Switch, 600 V AC/250 V DC, 60 A, 4 Poles, 3 WiresNon-stock product. Available to order - lead time may vary.
BrandAppleton
MFG #WSR6352
Werner Part #3791808
UPC781381718042
Non-stock product. Available to order - lead time may vary.
BrandAppleton
MFG #WSR6352
Werner Part #3791808
UPC781381718042
Product Description
Appleton Interlocked Receptacle, Fused Grounding Style 2, Series: WSR, 600 V AC/250 V DC, 60 A, 15 /50 hp, 50/60 Hz Frequency, 4 Pole, 3 Wires, NEMA 3/3R/4/4X/12 NEMA, 6 to 2 AWG Wire, Copper Free Aluminum, 22.25 in H x 10.5 in W x 10.31 in D Dimensions
Attributes
Documents
Applications
Features
Specifications
Attributes
Country of OriginUS
Dimensions22.25 in H x 10.5 in W x 10.31 in D
Frequency Rating50/60 Hz
Horsepower15 /50 hp
ManufacturerEmerson Electric
MaterialCopper Free Aluminum
NEMA RatingNEMA 3/3R/4/4X/12
Number of Poles4
Number of Wires3
Package Height8.15 IN
Package Length30.1 in
Package TypeEACH
Package Weight16.7 lb
Package Width19.5 in
SeriesWSR
Size of Wire6 to 2 AWG
TypeFused Grounding Style 2
Type / StyleFused Grounding Style 2
Voltage Rating600 V AC/250 V DC
Documents
Applications
Powertite ACP and CPH Plugs, Batch Feeder, Compressor, Conveyor, Generator, Industrial Plant, Infrared Oven, Marine Dock, Truck Terminal and Welder Applications
Features
- Shell and extra pole grounding style 2
- For use where an interlocked disconnect switch is desired to control a Powertite receptacle and insertion or removal of plug
- Short circuit withstand rated to 200000 RMS symmetrical amps
- Unit is equipped with defeatable door interlock which allows emergency access when switch is energized
- Cover can be padlocked closed
- Dead front design receptacle is not energized until plug is fully inserted and switch is engaged
- Without viewing window
- Corrosion resistant, raintight, watertight
Specifications
Standards/Approvals: ARRA Compliant|UL 98|UL 50E|UL 1682|UL 1686|UL File No. E145917|UL File No. E160652|CSA C22.2 No.4|C22.2 No. 182.1|CSA File No. 025875
