Leviton 5224-2W
Leviton 5224-2W Duplex Grounding AC Combination Switch With Receptacles, 15 A, 125 V AC, 1800 W, 1 Poles
Leviton 5224-2W
Leviton 5224-2W Duplex Grounding AC Combination Switch With Receptacles, 15 A, 125 V AC, 1800 W, 1 PolesIn Stock: 9more info
|
BrandLeviton
MFG #5224-2W
Werner Part #1052676
UPC078477226483
In Stock: 9more info
|
BrandLeviton
MFG #5224-2W
Werner Part #1052676
UPC078477226483
Product Description
Leviton AC Combination Switch, Duplex Grounding, 15 A, 125 V AC, 1800 W Electrical Rating, 1 Pole, 15 A at 120/277 VAC Contact, NEMA 5-15R Enclosure, Surface/Wall Plate Mounting, 4.2 in H x 1.62 in W x 16 in D Size, 100 Cycles Operating Cycles, Environmental Conditions: -40 to 120 deg C Operating Temperature, Thermoplastic, White
Attributes
Documents
Applications
Features
Specifications
Warranty
Attributes
ColorWhite
Country of OriginMX
Electrical Ratings15 A, 125 V AC, 1800 W
Enclosure TypeNEMA 5-15R
GTIN00078477226483
ManufacturerLeviton
MaterialThermoplastic
Mounting TypeSurface/Wall Plate
NEMA RatingNEMA 5-15R
Number of Poles1
Package TypeEACH
SeriesDuplex Grounding
Size4.2 in H x 1.62 in W x 16 in D
Temperature Rating-20 to 60 deg C Operating Temperature
TypeDuplex Grounding
Type / StyleDuplex Grounding
Documents
Applications
Commercial Applications
Features
- AC quiet switches have silver cadmium oxide contacts and receptacles have double wire contacts for maximum conductivity
- Terminal screw accept up to #12 AWG copper or copper clad wire
- Fits standard wallboxes
- Break-OFF tabs on devices with switches permit conversion to separate feeds
- Steel strap and thermoplastic toggle actuator
- Side wired terminal
- Dielectric voltage withstands 1500 VAC for 1 min
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C-73|UL 20 File No. E7458|CSA C22.2 No.111/152105/LR3413|NOM 057|NEMA WD-1/WD-6|UL94 V-2
Warranty
2 Years Limited
