nVent ILSCO PET-8-350-Z
ILSCO ClearChoice PET-8-350-Z Type PET Dual Rated Spade Transformer Lug, (8) 12 AWG to 350 kcmil Aluminum/Copper Conductor, 1/2 in Stud, Aluminum
nVent ILSCO PET-8-350-Z
ILSCO ClearChoice PET-8-350-Z Type PET Dual Rated Spade Transformer Lug, (8) 12 AWG to 350 kcmil Aluminum/Copper Conductor, 1/2 in Stud, AluminumNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
ILSCO ClearChoice Spade Transformer Lug, Type PET Dual Rated, Aluminum/Copper Conductor, 8 Conductors, 12 AWG to 350 kcmil Conductor, 1/2 in Stud, 600 V AC, 5/16 in Hex, 350 in-lb Torque, Aluminum, Wax Plated, 10-1/2 in L x 1-3/8 in W x 1 in H
Attributes
Documents
Applications
Features
Specifications
Attributes
Conductor size12 AWG to 350 kcmil
Conductor TypeAluminum/Copper
Country of OriginMX
Dimensions10-1/2 in L x 1-3/8 in W x 1 in H
FinishWax Plated
ManufacturerECM Industries
MaterialAluminum
Package TypeEACH
Stud Size1/2 in
TypeType PET Dual Rated
Type / StyleType PET Dual Rated
Voltage Rating600 V AC
Applications
For tap connector
Features
- Manufactured from high strength 6061-T6 aluminum for use with copper or aluminum wire
- Range taking for reduced inventories and flexibility
- Provides multiple conductor installation for a wide range of conductors
- Predrilled 1/2 in mounting holes allow easy attachment
- May be bolted back to back for heavy duty applications
- 1-3/4 in mounting hole spacing
- 9/16 in Dia mounting hole
Specifications
5/16 in Hex, 350 in-lb Torque
