Panduit FSD76-8-D
Panduit Pan-Term FSD76-8-D Type FSD Single Insulated Wire Ferrule, 18 AWG Stranded Conductor, 0.55 in L, Copper, Gray
Panduit FSD76-8-D
Panduit Pan-Term FSD76-8-D Type FSD Single Insulated Wire Ferrule, 18 AWG Stranded Conductor, 0.55 in L, Copper, GrayIn Stock: 9500more info
|
BrandPanduit
MFG #FSD76-8-D
Werner Part #53980
UPC074983762484
In Stock: 9500more info
|
BrandPanduit
MFG #FSD76-8-D
Werner Part #53980
UPC074983762484
Product Description
Panduit Pan-Term Wire Ferrule, Type FSD Single Insulated, Stranded Conductor, 18 AWG Conductor, 0.55 in Length, Seamless Barrel, 0.05 in ID x 0.31 in L Barrel, Specifications: 0.11 in Dia Maximum Wire Insulation, 15/32 in Mounting Hole, 15/32 in L Wire Strip, Polypropylene Insulation, 221 deg F, Copper, Tin Plated, Gray
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.05 in ID x 0.31 in L
Barrel TypeSeamless
ColorGray
Conductor size18 AWG
Conductor TypeStranded
Country of OriginDE
FinishTin Plated
ManufacturerPanduit
MaterialCopper
Package Height0.85 in
Package Length4.8 IN
Package Volume17915.9 cu-in
Package Weight0.1 lb
Package Width3 in
Temperature Rating221 deg F
TypeType FSD Single Insulated
Type / StyleType FSD DIN End Sleeve Single Insulated
Documents
Applications
Limited Space Panel Applications
Features
- Polypropylene insulation
- Meets DIN standards for twin wire containment
- Funnel entry for faster insertion and lower installed cost
- Designed with a seamless barrel to contain loose wire strands for superior terminations
- Designed with a seamless barrel to contain loose wire strands for superior terminations
- Eases insertion of wire into terminal block
- Meets DIN, UL and CSA standards for wire containment
Specifications
0.11 in Dia Maximum Wire Insulation, 15/32 in Mounting Hole, 15/32 in L Wire Strip, Polypropylene Insulation
