Panduit FSD81-12-C
Panduit Pan-Term FSD81-12-C Type FSD Single Insulated Wire Ferrule, 12 AWG Stranded Conductor, 0.79 in L, Copper, Gray
Panduit FSD81-12-C
Panduit Pan-Term FSD81-12-C Type FSD Single Insulated Wire Ferrule, 12 AWG Stranded Conductor, 0.79 in L, Copper, GrayOut of Stockmore info
|
Out of Stockmore info
|
Product Description
Panduit Pan-Term Wire Ferrule, Type FSD Single Insulated, Stranded Conductor, 12 AWG Conductor, 0.79 in Length, Seamless Barrel, 0.11 in ID x 0.47 in L Barrel, Specifications: 0.19 in Dia Maximum Wire Insulation, 5/8 in Mounting Hole, 5/8 in L Wire Strip, Polypropylene Insulation, 221 deg F, Copper, Tin Plated, Gray
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.11 in ID x 0.47 in L
Barrel TypeSeamless
ColorGray
Conductor size12 AWG
Conductor TypeStranded
Country of OriginDE
FinishTin Plated
ManufacturerPanduit
MaterialCopper
Temperature Rating221 deg F
TypeType FSD Single Insulated
Documents
Applications
Limited Space Panel Applications
Features
- Designed with a seamless barrel to contain loose wire strands for superior terminations eases insertion of wire into terminal block
- Funnel entry for faster insertion and lower installed cost
- Designed with a seamless barrel to contain loose wire strands for superior terminations
- Eases insertion of wire into terminal block
Specifications
0.19 in Dia Maximum Wire Insulation, 5/8 in Mounting Hole, 5/8 in L Wire Strip, Polypropylene Insulation
