Panduit FSD74-8-D
Panduit Pan-Term FSD74-8-D Type FSD Single Insulated Wire Ferrule, 22 AWG Stranded Conductor, 0.49 in L, Copper, Turquoise
Panduit FSD74-8-D
Panduit Pan-Term FSD74-8-D Type FSD Single Insulated Wire Ferrule, 22 AWG Stranded Conductor, 0.49 in L, Copper, TurquoiseIn Stock: 1000more info
|
BrandPanduit
MFG #FSD74-8-D
Werner Part #53976
UPC074983763986
In Stock: 1000more info
|
BrandPanduit
MFG #FSD74-8-D
Werner Part #53976
UPC074983763986
Product Description
Panduit Pan-Term Wire Ferrule, Type FSD Single Insulated, Stranded Conductor, 22 AWG Conductor, 0.49 in Length, Seamless Barrel, 0.03 in ID x 0.31 in L Barrel, Specifications: 0.07 in Dia Maximum Wire Insulation, 15/32 in Mounting Hole, 15/32 in L Wire Strip, Polypropylene Insulation, 221 deg F, Copper, Tin Plated, Turquoise
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.03 in ID x 0.31 in L
Barrel TypeSeamless
ColorTurquoise
Conductor size22 AWG
Conductor TypeStranded
Country of OriginDE
FinishTin Plated
ManufacturerPanduit
MaterialCopper
Temperature Rating221 deg F
TypeType FSD Single Insulated
Type / StyleType FSD DIN End Sleeve Single Insulated
Documents
Applications
Limited Space Panel Applications
Features
- Polypropylene insulation
- Meets DIN standards for twin wire containment
- Funnel entry for faster insertion and lower installed cost
- Designed with a seamless barrel to contain loose wire strands for superior terminations
- Eases insertion of wire into terminal block
Specifications
0.07 in Dia Maximum Wire Insulation, 15/32 in Mounting Hole, 15/32 in L Wire Strip, Polypropylene Insulation
