nVent ILSCO IPC-250-4/0-B
ILSCO KUP-L-Tap IPC-250-4/0-B Type IPC Dual Rated Insulation Piercing Connector, 1 AWG to 250 kcmil Aluminum/Copper Conductor, 5/8 in, Copper
nVent ILSCO IPC-250-4/0-B
ILSCO KUP-L-Tap IPC-250-4/0-B Type IPC Dual Rated Insulation Piercing Connector, 1 AWG to 250 kcmil Aluminum/Copper Conductor, 5/8 in, CopperNon-stock product. Available to order - lead time may vary.
BrandnVent ILSCO
MFG #IPC-250-4/0-B
Werner Part #2385703
UPC783669532920
Non-stock product. Available to order - lead time may vary.
BrandnVent ILSCO
MFG #IPC-250-4/0-B
Werner Part #2385703
UPC783669532920
Product Description
ILSCO KUP-L-Tap Insulation Piercing Connector, Type IPC Dual Rated, Aluminum/Copper Conductor, 1 AWG to 250 kcmil Conductor, 5/8 in Bolt, 600 V AC, 30 ft-lb Torque, 260 A Copper, 205 A Aluminum, 90 deg C, Copper, Tin Plated, Black, 3-11/32 in H x 2-11/32 in W
Attributes
Documents
Features
Specifications
Attributes
ColorBlack
Conductor size1 AWG to 250 kcmil
Conductor TypeAluminum/Copper
Country of OriginMX
Dimensions3-11/32 in H x 2-11/32 in W
FinishTin Plated
ManufacturerECM Industries
MaterialCopper
Package TypeBag
Temperature Rating90 deg C
TypeType IPC Dual Rated
Type / StyleType IPC Dual Rated
Voltage Rating600 V AC
Documents
Features
- Body is molded from tough, resilient glass filled nylon provides high degree of breakage resistance and long dependable use
- Compact design saves space
- Tin plated copper contact teeth easily penetrates most types of insulation
- Insulation piercing, no need to strip the conductor which saves installation time
- Perforated end tabs break out easily by hand
- Pre-filled with silicone lubricant prevents oxidation and moisture from entering the contact area
- Versatile - can be used as a splice or tap connector
- Increased safety - contains no external energized parts, can be installed "hot" on energized conductors providing tap conductor is not under load
- Horizontal line grid provides a visual guide for proper installation of conductors
- For use with class B or C stranded conductor
- 6 to 4/0 AWG tap/secondary conductor size
Specifications
30 ft-lb Torque, 260 A Copper, 205 A Aluminum
