nVent ILSCO CT-4
ILSCO SureCrimp CT-4 CT Series Short Barrel Compression Sleeve, 4 AWG Copper Conductor, Die Code: I-29, 1-7/8 in L, Copper
nVent ILSCO CT-4
ILSCO SureCrimp CT-4 CT Series Short Barrel Compression Sleeve, 4 AWG Copper Conductor, Die Code: I-29, 1-7/8 in L, CopperNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
ILSCO SureCrimp Compression Sleeve, Short Barrel, Series: CT Series, Copper Conductor, 4 AWG Conductor, Die Code: I-29, 1-7/8 in Length, Crimp Connector, 600 V AC, 90 deg C, 1 in L Stripe, Copper, Electro-Plated Tin, Gray, 0.25 in ID x 0.343 in OD
Attributes
Documents
Applications
Features
Specifications
Attributes
ColorGray
Conductor size4 AWG
Conductor TypeCopper
Country of OriginMX
Die CodeI-29
Dimensions0.25 in ID x 0.343 in OD
FinishElectro-Plated Tin
ManufacturerECM Industries
MaterialCopper
Package TypeEACH
SeriesCT Series
Temperature Rating90 deg C
TypeShort Barrel
Type / StyleShort Barrel
Voltage Rating600 V AC
Applications
For use with splicer/reducer, grounding and bonding applications
Features
- Manufactured from high strength seamless copper tubing and electro-tin plated
- Short with chamfered end barrel, center wire stop
- Proper high voltage spacing and insulation techniques must be used, for high voltage applications up to 35 kV
- For copper conductor only copper class B concentric/compressed, class C concentric strand configurations
- Listed with ILSCO tools ILC-12, ILC-12H, ILCB-12, ILC-14, ILC-14H, ILC-15, MT-25, 94285, IDT-12, IDT-12H, ILC-10 and IDTB-12
- Provides low contact resistance, maximum conductivity and excellent crimping characteristics and versatility
- Provides easy conductor insertion and insures maximum cable insertion
- Color code identifies the proper compression die
- Expanded wire size with ILSCO dieless tools and BURNDY Y644M dieless tool
- Reduces inventory requirements
- 4 AWG solid alternate conductor size
- 6 to 4 AWG expanded conductor
- Insures maximum cable insertion
Specifications
1 in L Stripe
