nVent ILSCO ACM-250
ILSCO ClearChoice ACM-250 Dual Rated Pigtail Adapter With Insulating Cover, 250 kcmil Conductor, Die Code: 14, 0.47 in Dia x 1.22 in L Pin, Aluminum
nVent ILSCO ACM-250
ILSCO ClearChoice ACM-250 Dual Rated Pigtail Adapter With Insulating Cover, 250 kcmil Conductor, Die Code: 14, 0.47 in Dia x 1.22 in L Pin, AluminumNon-stock product. Available to order - lead time may vary.
BrandnVent ILSCO
MFG #ACM-250
Werner Part #2370820
UPC783669009163
Non-stock product. Available to order - lead time may vary.
BrandnVent ILSCO
MFG #ACM-250
Werner Part #2370820
UPC783669009163
Product Description
ILSCO ClearChoice Pigtail Adapter, Dual Rated, Series: ACM, 250 kcmil Conductor, Die Code: 14, Brown Color Code, 0.47 in Pin Diameter, 1.22 in Pin Length, 1.7 in Barrel Length, 600 V AC, Specifications: 2-1/4 in L Cover, 3/0 AWG Pin, 39/64 in ID x 1-7/64 in OD, Aluminum
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Length1.7 in
Conductor size250 kcmil
Country of OriginMX
Die Code14
ManufacturerECM Industries
MaterialAluminum
Package Height1.29 in
Package Length3.8 in
Package TypeEACH
Package Weight0.17 lb
Package Width1.29 in
Pin Length1.22 in
SeriesACM
TypeDual Rated
Type / StyleDual Rated
Voltage Rating600 V AC
Applications
For terminating connector
Features
- Manufactured from high strength aluminum alloy provides maximum conductivity and excellent crimping characteristics
- Pin is knurled which permits greater surface contact, chamfered barrel which provides easy conductor insertion
- Color coded end caps inserted in barrel which prevents foreign materials from entering the connector prior to usage and color code identifies the proper compression die
- Pre-filled with DE-OX prevents oxide from forming
- Stranded class B and C concentric, compressed and unidirectional lay compact
- Rated for full ampacity of incoming conductor
- Clearly marked with conductor size and die index which provides easy identification and tooling recommendation
- Marked with number and location of crimps and color coded
- All supplied with insulating cover which eliminates taping, temperature range is 90 deg C and ensures reliability for aluminum or copper conductors
- Provides easy identification and tooling recommendation
Specifications
2-1/4 in L Cover, 3/0 AWG Pin, 39/64 in ID x 1-7/64 in OD
