General Cable AP0121PNU
General Cable NextGen AP0121PNU Distribution Single-Mode Tight Buffer Plenum Fiber Optic Cable, Reel Packaging, 12 Fiber
General Cable AP0121PNU
General Cable NextGen AP0121PNU Distribution Single-Mode Tight Buffer Plenum Fiber Optic Cable, Reel Packaging, 12 FiberIn Stock: 6240more info
|
In Stock: 6240more info
|
Product Description
General Cable NextGen Fiber Optic Cable, Distribution Single-Mode Tight Buffer Plenum, Reel Packaging, 12 Fibers, 1 dB/km Attenuation, PVC Insulation, PVC/Fluoropolymer Jacket, Yellow Jacket, -40 to 158 deg F
Attributes
Documents
Applications
Warranty
Features
Specifications
Attributes
Attenuation1 dB/km
Country of OriginUS
Fiber Count12
Insulation MaterialPVC
Jacket ColorYellow
Jacket MaterialPVC/Fluoropolymer
ManufacturerPrysmian
Package TypeREEL
Temperature Rating-40 to 158 deg F
TypeDistribution Single-Mode Tight Buffer Plenum
Documents
Applications
For intrabuilding voice or data communication Back-Bones and installation in ducts, plenums and other spaces used as environmental air returns
Warranty
12 Months
Features
- Lightweight, flexible design simplifies installation
- Tight buffer provides individual fiber protection
- Tight buffered fibers are easy-to handle and strip for field connectorization
- Sub units are numbered for identification
- Sequential footage marked to facilitate installation
- Orange jacket multi-mode fibers (except 10 Gbps)
- Aqua jacket 10 Gbps multi-mode fibers
- Yellow jacket single mode fibers
- Epoxy/glass rod (P1D) central strength member
- Aramid fiber yarn overall strength member
- 20 X OD installation, 10 X OD in-service maximum bend radius
- 850 lb/in maximum crush resistance
- 320 lb installation, 112 lb in-service maximum tensile load
- Tight buffer SM, SMF-28 ultra fiber
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS 2002/95/EC|ETL Type OFNP|CSA FT6|TIA/EIA 568 C.3|ICEA S-83-596|GR-409|NEC Article 770-51 (a)/770-53 (a)
