Advance IZT2T42M5LD35M
Advance IZT2T42M5LD35M Controllable Electronic Dimmable Compact Fluorescent Ballast, 42 W Lamp, 120 to 277 VAC, Programmed, 0.03 to 1 Ballast Factor
Advance IZT2T42M5LD35M
Advance IZT2T42M5LD35M Controllable Electronic Dimmable Compact Fluorescent Ballast, 42 W Lamp, 120 to 277 VAC, Programmed, 0.03 to 1 Ballast FactorNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Advance Dimmable Compact Fluorescent Ballast, Controllable Electronic, 42 W Lamp, 18 to 98 W Wattage, 120 to 277 VAC, 0.36 to 0.82 A, 50/60 Hz Frequency, Programmed Start, Total Harmonic Distortion: 10 %, Power Factor: 0.99, Yes Dimmable, 2 Lamps, GX24Q 4-Pin Lamp Base, Ballast Factor: 0.03 to 1, 70 deg C, Metal, 4.55 in L x 3 in W x 1.29 in H Dimensions
Attributes
Documents
Applications
Features
Attributes
Ballast Factor0.03 to 1
Country of OriginUS
Dimensions4.55 in L x 3 in W x 1.29 in H
DimmableYes
Frequency Rating50/60 Hz
Lamp Base TypeGX24Q 4-Pin
Lamp TypeCFL
Lamp Wattage42 W
ManufacturerSignify
MaterialMetal
Number of Lamps2
Package TypeEACH
Power Factor0.99
Start TypeProgrammed
Temperature Range70 deg C
Total Harmonic Distortion10 %
TypeControllable Electronic
Type / StyleControllable Electronic
Voltage Rating120 to 277 V AC
Wattage18 to 98 W
Applications
Conference Rooms, Private Offices, Auditoriums, Architectural Cove, Auditoriums, Educational Facilities, Hotels, Restaurants and Department Stores Applications
Features
- Triple CFL series lamp connection
- Blue color label identification
- 20 to 24 dB average ambient noise level
- High power factor
- Length mounting feet with SmartMate dual entry color coded connectors
- Available in linear fluorescent and 4-pin compact fluorescent models
- Full range continuous dimming (100% light output down to 5% - T5HO to 1%)
- IntelliVolt technology (120 to 277 VAC, 50/60 Hz)
- Compatible with controls from numerous manufacturers without using standards 0 to 10 VDC controls
- Ideal for frequent switching applications such as occupancy sensors and daylight harvesting - programmed start operation
