Cutler-Hammer Series D8PR7TEA
EATON D8PR7TEA Fixed Contact Standard General Purpose Relay, 25 A, 1NO 1 Form A DPST Contact, 120 V AC V Coil
Cutler-Hammer Series D8PR7TEA
EATON D8PR7TEA Fixed Contact Standard General Purpose Relay, 25 A, 1NO 1 Form A DPST Contact, 120 V AC V CoilOut of Stockmore info
|
BrandCutler-Hammer Series
MFG #D8PR7TEA
Werner Part #3759909
UPC782114161197
Out of Stockmore info
|
BrandCutler-Hammer Series
MFG #D8PR7TEA
Werner Part #3759909
UPC782114161197
Product Description
EATON General Purpose Relay, Fixed Contact Standard, Series: D8 Series, 25 A, 1-1/2 hp, 3 hp Power, 50/60 Hz Frequency, 120 V AC Coil, 1NO 1 Form A DPST Contact Form, 15 A Contact, 2 Pole, E-Bracket Mounting, Plug-In Terminal, 2.07 in L x 1.32 in W x 2.09 in H Dimensions
Attributes
Documents
Applications
Features
Warranty
Attributes
Coil Voltage120 V AC
Contact Form1NO 1 Form A DPST
Contact Rating15 A
Country of OriginID
Dimensions2.07 in L x 1.32 in W x 2.09 in H
Frequency Rating50/60 Hz
ManufacturerEaton
Mounting TypeE-Bracket
Number of Poles2
Package Length1.7 in
Package TypeEACH
Package Weight0.22 lb
Package Width1.7 in
Power Rating1-1/2 hp, 3 hp
SeriesD8 Series
Terminal TypePlug-In
Applications
Commercial, Institutional Buildings and Structures
Features
- A high capacity, high withstand voltage relay compatible with momentary voltage drops
- No contact chattering for momentary voltage drops up to 50% of rated voltage
- UL class B construction standard
- Wide range AC activated coil that handles 100 to 120 VAC at either 50 or 60 Hz
- 1-1/2 hp at 120 VAC, 3 hp at 240/265/277 VAC rating
Warranty
1 year
