Cutler-Hammer Series PSG120E24RM
EATON PSG120E24RM 1-Phase Switcher DC Power Supply, 100 to 240 V AC Input, 24 VDC Output, 120 W Power Rating, 2.2/5 A, DIN Rail Mount
Cutler-Hammer Series PSG120E24RM
EATON PSG120E24RM 1-Phase Switcher DC Power Supply, 100 to 240 V AC Input, 24 VDC Output, 120 W Power Rating, 2.2/5 A, DIN Rail MountOut of Stockmore info
|
BrandCutler-Hammer Series
MFG #PSG120E24RM
Werner Part #4050013
UPC786685520988
Out of Stockmore info
|
BrandCutler-Hammer Series
MFG #PSG120E24RM
Werner Part #4050013
UPC786685520988
Product Description
EATON DC Power Supply, 1-Phase Switcher, Series: PSG, 100 to 240 V AC Input, 24 VDC Output, 120 W Power, 2.2/5 A, 47/63 Hz Frequency, DIN Rail Mounting, Metal Case, 1.9685 in Width, 3.8583 in Depth, 3 in Height
Attributes
Documents
Applications
Features
Warranty
Attributes
Country of OriginTH
Depth3.8583 in
Frequency Rating47/63 Hz
Height3 in
ManufacturerEaton
Mounting TypeDIN Rail
Package TypeEACH
Power Rating120 W
SeriesPSG
Type / StyleSKU
Width1.9685 in
Applications
Electrical Assemblies, Panels and OEMs Applications
Features
- 150% power surge output
- MTBF up to >800000 hr ensures uptime and reliability
- Protection from overvoltage, over current and over temperature conditions
- Rugged aluminum and plastic housings provide the durability required to stand up to harsh environments
- All metal DIN rail mounting hardware
- LED indicating light for DC OK simplifies troubleshooting
- Conformal coated electronics
- Hazardous location class I, division 2 rated models
- NEC class 2 rated model
- Redundancy modules keep loads up and running in the event of a device failure
- Buffer module has the stored power needed to keep loads running through a short duration power failure
- Fixed finger safe terminals
- >92% at 3 x 400 VAC and 3 x 500 VAC efficiency
- PSG480R24RM/PSG960R24RM with O-ring diode parallel operation
- 18 to 12 AWG wire conductors
Warranty
1 year
