Cutler-Hammer Series 12100RQD07
EATON Perfect Prox 12100RQD07 Comet Forward Viewing Photoelectric Sensor, Tubular Shape, 20 ft, Visible Red Sensing Beam, 3.5 ms Response, NPN/PNP Open Collector Output
Cutler-Hammer Series 12100RQD07
EATON Perfect Prox 12100RQD07 Comet Forward Viewing Photoelectric Sensor, Tubular Shape, 20 ft, Visible Red Sensing Beam, 3.5 ms Response, NPN/PNP Open Collector OutputNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #12100RQD07
Werner Part #2382105
UPC782113843490
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #12100RQD07
Werner Part #2382105
UPC782113843490
Product Description
EATON Perfect Prox Photoelectric Sensor, Forward Viewing, Series: Comet, Tubular Shape, Thru-Beam Sensing Method, 20 ft Sensing, Visible Red Sensing Beam, 3.5 ms Response, NPN/PNP Open Collector Output, 10 to 30 V DC, 100/250 mA, 1 W Wattage, 50/60 Hz Frequency, 4-Pin M12 Connection, Output On LED Indicator Light Source, 30 g Vibration, 2.55 in L x 0.47 in W x 0.71 in H Size, NEMA 1/3/4/4X/6/12/13/IP69K Enclosure, -4 to 158 deg F Operating, Surface Mounting
Attributes
Documents
Applications
Warranty
Features
Attributes
Connection Type4-Pin M12
Country of OriginMX
Enclosure TypeNEMA 1/3/4/4X/6/12/13/IP69K
Frequency Rating50/60 Hz
ManufacturerEaton
Mounting TypeSurface
Operating Temperature-4 to 158 deg F
Package TypeEACH
SeriesComet
ShapeTubular
Size2.55 in L x 0.47 in W x 0.71 in H
Type / StyleSKU
Wattage1 W
Documents
Applications
Automation and Logic Control Equipment, Vehicles On-Road PickUp and Delivery Food Applications
Warranty
3 years
Features
- Industry standard 18 mm Dia threaded body has flat sides allowing it to be mounted like a tubular sensor or against any flat surface
- Perfect Prox technology provides exceptional background rejection and application problem solving
- Visible sensing beams let you see where the beam is aimed for quick-setup and alignment
- Solid polyurethane housing completely encapsulates internal circuits for high resistance to shock and vibration
- Adaptable modulation circuit provides immunity to crosstalk from other closely mounted sensors
- The industry's only background rejection sensors with a 2-wire circuit design
- 4-wire DC sensors offer both NPN and PNP outputs
- Output status indicator visible from a wide 270 deg angle
- Polycarbonate cable lens, PVC jacket, structural polyurethane foam body enclosure material
- Auto-reset short circuit protection
- Right angle viewing models mount in a depth of only 6/10th of an inch
