Cutler-Hammer Series C25FNF350A
EATON C25FNF350A Non-Reversing Definite Purpose Contactor With Metal Mounting Plate, 110 to 120 V AC at 50/60 Hz V Coil, 50 A Inductive/65 A Resistive, 3 Poles
Cutler-Hammer Series C25FNF350A
EATON C25FNF350A Non-Reversing Definite Purpose Contactor With Metal Mounting Plate, 110 to 120 V AC at 50/60 Hz V Coil, 50 A Inductive/65 A Resistive, 3 PolesIn Stock: 3more info
|
In Stock: 3more info
|
Product Description
EATON Definite Purpose Contactor, Non-Reversing, 110 to 120 V AC at 50/60 Hz Coil, 50 A Inductive/65 A Resistive Maximum Load Current, 3 Pole, Quick-Connect (Side by Side) Connection, Box Lug Terminal, Open Enclosure, 3.97 in L x 2.63 in W x 3.75 in H Dimensions
Attributes
Documents
Applications
Features
Specifications
Attributes
Coil Voltage110 to 120 V AC at 50/60 Hz
Connection TypeQuick-Connect (Side by Side)
Country of OriginDO
Dimensions3.97 in L x 2.63 in W x 3.75 in H
Enclosure TypeOpen
ManufacturerEaton
Maximum Load Current50 A Inductive/65 A Resistive
Number of Poles3
Package TypeEACH
Terminal TypeBox Lug
Type / StyleNon-Reversing
Documents
Applications
For motor and power control equipment
Features
- Completely encased design impervious to dust and other environmental elements
- 1, 2, 3 and 4-pole configurations
- Open components and enclosed designs
Specifications
- Resistive Load: 65A
- Standard: UL Recognized; CSA Certified
- Terminals: Box lugs (posidrive setscrew) and quick connect terminals (side-by-side)
