Bussmann Series MDQ-1
Edison MDQ-1 MDQ Small Dimension Time Delay Fuse With Nickel Plated Brass End Caps, 1 A, 250 V AC, 35 A Interrupt, Cylindrical Body
Bussmann Series MDQ-1
Edison MDQ-1 MDQ Small Dimension Time Delay Fuse With Nickel Plated Brass End Caps, 1 A, 250 V AC, 35 A Interrupt, Cylindrical BodyNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Edison Time Delay Fuse, Small Dimension, Series: MDQ, Non-Indicating, Non-Rejection, 1 A, 250 V AC, 35 A Interrupt, 60 min, 120 s Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Glass, 1/4 in Dia x 1-1/4 in L Body Size
Attributes
Documents
Applications
Features
Attributes
Body Size1/4 in Dia x 1-1/4 in L
Body TypeCylindrical
Country of OriginMX
ElementDual
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating35 A
ManufacturerEaton
MaterialGlass
Mounting TypeClip/Holder
Rejection/Non-RejectionNon-Rejection
Response Time60 min, 120 s
SeriesMDQ
Terminal TypeFerrule
Type / StyleSmall Dimension
Voltage Rating250 V AC
Documents
Applications
Electronic Relay and Control Circuit Applications
Features
- Dual element design allows closer sizing to inductive circuits than any other fuses
- 35 A at 250 VAC interrupt rating
- 60 min maximum at 135%, 120 sec maximum at 200% response time
