Bussmann Series NON-15
Bussmann NON-15 One-Time General Purpose Fast Acting Non-Current Limiting Fuse, 15 A, 250 V AC/125 V DC, 50 kAIC Interrupt, Class: H, Cylindrical Body
Bussmann Series NON-15
Bussmann NON-15 One-Time General Purpose Fast Acting Non-Current Limiting Fuse, 15 A, 250 V AC/125 V DC, 50 kAIC Interrupt, Class: H, Cylindrical BodyNon-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #NON-15
Werner Part #22933
UPC051712101561
Non-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #NON-15
Werner Part #22933
UPC051712101561
Product Description
Bussmann Fuse, One-Time General Purpose Fast Acting Non-Current Limiting, Series: NON, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 15 A, 250 V AC/125 V DC, 50 kAIC Interrupt, Class: H, Ferrule End Terminal, Holder Mount, Cylindrical Body Type, Single Element, Melamine, 0.56 in Dia x 2 in L Body Size
Attributes
Documents
Applications
Features
Attributes
Body Size0.56 in Dia x 2 in L
Body TypeCylindrical
ClassH
Country of OriginMX
ElementSingle
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating50 kAIC
ManufacturerEaton
MaterialMelamine
Mounting TypeHolder
Package Height2 in
Package Length2 in
Package TypeEACH
Package Weight0.35 lb
Package Width0.56 in
Rejection/Non-RejectionRejection
SeriesNON
Terminal TypeFerrule End
Voltage Rating250 V AC/125 V DC
Applications
Industrial Facilities and Factory Facility, Safety and Security Systems, Light Duty Circuit Locations Applications
Features
- Protect lighting, heating and other circuits not subject to temporary surges and where available short circuit currents are relatively low
- One-time fuses do not have any appreciable degree of time delay and thus should not be specified in circuits where large transients or motor overloads occur
- Use Bussmann advanced protection Fusetron FRN-R or ultimate protection Low-Peak LPN-RK dual element, time delay fuses
- For general purpose circuits, size at amp rating of circuit
- For motor circuits, size at 300% to 400% according to the NEC motor ampacity tables 430.247/430.250/ 430.6(A)(1)
- One-time fuse
