Bussmann Series FWP-50A14F
Edison FWP-50A14F Fast Acting High Speed Fuse, 50 A, 690/700 VAC, 800 VDC, 50/200 kA, Cylindrical Body
Bussmann Series FWP-50A14F
Edison FWP-50A14F Fast Acting High Speed Fuse, 50 A, 690/700 VAC, 800 VDC, 50/200 kA, Cylindrical BodyIn Stock: 29more info
|
In Stock: 29more info
|
Product Description
Edison High Speed Fuse, Fast Acting, Series: FWP, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 50 A, 690/700 VAC, 800 VDC, 50/200 kA Interrupt, Ferrule Terminal, Holder Mount, Cylindrical Body, Single Element, Fiberglass, 0.563 in Dia x 2 in L Body Size
Attributes
Documents
Applications
Features
Attributes
Body Size0.563 in Dia x 2 in L
Body TypeCylindrical
ClassaR
Country of OriginIN
ElementSingle
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating50/200 kA
ManufacturerEaton
MaterialFiberglass
Mounting TypeHolder
Rejection/Non-RejectionNon-Rejection
SeriesFWP
Terminal TypeFerrule
Type / StyleFast Acting
Voltage Rating690 to 700 V AC/800 V DC
Documents
Applications
DC Common Bus, DC Drives, Power Converters/Rectifiers and Reduced Voltage Starters Applications
Features
- Excellent cycling capability and DC performance
- Low arc voltage and low energy let through
- Low watts loss in a compact size
- Used with finger safe holders/blocks
- Superior cycling capability
