Cutler-Hammer Series 5ACLS-4R
EATON Ampgard Bussmann 5ACLS-4R ACLS Medium Voltage Single Barrel Current-Limiting Fuse, 130 A, 5.5 kV, 50 kA Interrupt, Class R
Cutler-Hammer Series 5ACLS-4R
EATON Ampgard Bussmann 5ACLS-4R ACLS Medium Voltage Single Barrel Current-Limiting Fuse, 130 A, 5.5 kV, 50 kA Interrupt, Class RNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Ampgard Bussmann Current-Limiting Fuse, Medium Voltage Single Barrel, Series: ACLS, 130 A, 5.5 kV, 50 kA Interrupt, Class: R, 15.9 x 3 x 3 in Body
Attributes
Documents
Applications
Included
Features
Attributes
Body Size15.9 x 3 x 3 in
ClassR
Country of OriginDO
Interrupt Rating50 kA
ManufacturerEaton
Package TypeEACH
SeriesACLS
Type / StyleMedium Voltage Single Barrel
Voltage Rating5.5 kV
Applications
Motor Starters and Circuit Protection Applications
Included
End Fittings
Features
- Current limiting R-rated fuses are physically dimensioned for easy installation in existing hardware
- These fuses are in a self-contained, non-venting package for installation indoors/outdoors in an enclosure
- These are designed for silent operation and elimination of flame discharges when the fuse operates
- Fuses are equipped with an indicator that will protrude indicating when a fuse has operated
- Space economy because the design of these fuses has eliminated flame or gas discharge, the need for exhaust control devices, vents and reinforcing is eliminated
- These fuses ensure positive interruption of high fault currents
- Controlled "crimping" of the silver elements during fuse manufacture permits CLS type current limiting fuses to withstand severe duty cycling without failure
