Littelfuse L60030C-1PQ
Littelfuse POWR-GARD L60030C-1PQ Fuse Block, 600 V AC/DC, 30 A, Class: CC, 14 to 10 AWG Wire, 1 Pole
Littelfuse L60030C-1PQ
Littelfuse POWR-GARD L60030C-1PQ Fuse Block, 600 V AC/DC, 30 A, Class: CC, 14 to 10 AWG Wire, 1 PoleIn Stock: 207more info
|
BrandLittelfuse
MFG #L60030C-1PQ
Werner Part #4137000
UPC079458070071
In Stock: 207more info
|
BrandLittelfuse
MFG #L60030C-1PQ
Werner Part #4137000
UPC079458070071
Product Description
Littelfuse POWR-GARD Fuse Block, Series: L600C, 600 V AC/DC, 30 A, 1 Pole, Class: CC, Pressure Plate Connection, 14 to 10 AWG Wire, DIN Rail Mounting, 1-1/2 in Fuse Length, 13/32 in Diameter Fuse, 125 deg C, For Use With: CCMR, KLDR and KLKR Series Fuse, Thermoplastic, 3 in L x 0.783 in W x 1.25 in H Dimensions
Attributes
Documents
Features
Attributes
ClassCC
Connection TypePressure Plate
Country of OriginCN
Dimensions3 in L x 0.783 in W x 1.25 in H
Fuse Diameter13/32 in
Fuse Length1-1/2 in
ManufacturerLittelfuse
MaterialThermoplastic
Mounting TypeDIN Rail
Number of Poles1
Package TypeEACH
SeriesL600C
Size of Wire14 to 10 AWG
Suitable For Use WithCCMR, KLDR and KLKR Series Fuse
Temperature Rating125 deg C
Voltage Rating600 V AC/DC
Documents
Features
- Space saving design
- Universal mounting holes for easy replacement
- Indication offered on CD blocks
- Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings
- Clip design reduces resistance and heat
- 1200 VAC minimum dielectric strength
- Covers available for all amperages to enhance safety
- Copper box lug
- Zinc plated steel screw and captive pressure plate
- Tin plated copper alloy clip/terminals
- Lead-free
- 2.3 N-m torque
- Pressure plate with quick connect terminal
- Cu solid/stranded wire
- One hand release from DIN rail optional
