Bussmann Series FNQ-R-2
Bussmann CC-Tron FNQ-R-2 Current Limiting High Inrush Time Delay Fuse, 2 A, 600 V, 200 kA Interrupt, CC Class, Cylindrical Body
Bussmann Series FNQ-R-2
Bussmann CC-Tron FNQ-R-2 Current Limiting High Inrush Time Delay Fuse, 2 A, 600 V, 200 kA Interrupt, CC Class, Cylindrical BodyIn Stock: 117more info
|
BrandBussmann Series
MFG #FNQ-R-2
Werner Part #21862
UPC051712147064
In Stock: 117more info
|
BrandBussmann Series
MFG #FNQ-R-2
Werner Part #21862
UPC051712147064
Product Description
Bussmann CC-Tron Time Delay Fuse, Current Limiting High Inrush, Series: FNQ-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 2 A, 600 V, 200 kA Interrupt, Class: CC, 12 s at 200% Response, Ferrule Terminal, Holder Mount, Cylindrical Body Type, Dual Element, Melamine, 13/32 in Dia x 1-1/2 in L Body Size
Attributes
Documents
Applications
Features
Specifications
Attributes
Body Size13/32 in Dia x 1-1/2 in L
Body TypeCylindrical
ClassCC
Country of OriginMX
ElementDual
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating200 kA
ManufacturerEaton
MaterialMelamine
Mounting TypeHolder
Package TypeEACH
Rejection/Non-RejectionRejection
Response Time12 s at 200%
SeriesFNQ-R
Terminal TypeFerrule
Type / StyleCurrent Limiting, High Inrush Time Delay
Voltage Rating600 V
Applications
Line Protection, Small Control Transformers, Industrial Control, Isolated and In-Line Fuse Holders Applications, Safety and Security Systems
Features
- Time delay compatible with inrush characteristic of small control transformers
- Current limitation at class CC levels provides maximum component short circuit current rating protection
- 200 kA interrupting rating provides high ratings for control circuit locations
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
- 12 s at 200% response time
- Nickel plated brass end caps
Specifications
Standard: UL 248-4, CSA, CE
