Littelfuse KLLU800
Littelfuse POWR-GARD KLLU800 Current Limiting Economical Time Delay Fuse, 800 A, 600 V AC/300 V DC, 20/200 kA Interrupt, L Class, Cartridge Body
Littelfuse KLLU800
Littelfuse POWR-GARD KLLU800 Current Limiting Economical Time Delay Fuse, 800 A, 600 V AC/300 V DC, 20/200 kA Interrupt, L Class, Cartridge BodyIn Stock: 2more info
|
BrandLittelfuse
MFG #KLLU800
Werner Part #46840
UPC079458271034
In Stock: 2more info
|
BrandLittelfuse
MFG #KLLU800
Werner Part #46840
UPC079458271034
Product Description
Littelfuse POWR-GARD Time Delay Fuse, Current Limiting Economical, Series: KLLU, Non-Indicating, 800 A, 600 V AC/300 V DC, 20/200 kA Interrupt, Class: L, Knife Blade Terminal, Bolt Mounting, Cartridge Body, Melamine, 2 in Dia x 8.63 in L Body
Attributes
Documents
Applications
Features
Attributes
Body Size2 in Dia x 8.63 in L
Body TypeCartridge
ClassL
Country of OriginMX
Indicating/Non-IndicatingNon-Indicating
Interrupt Rating20/200 kA
ManufacturerLittelfuse
MaterialMelamine
Mounting TypeBolt
Package Height3 in
Package Length12 in
Package TypeEACH
Package Weight3.63 lb
Package Width3 in
SeriesKLLU
Terminal TypeKnife Blade
Type / StyleCurrent Limiting Economical
Voltage Rating600 V AC/300 V DC
Documents
Applications
Service Switches, Switchboard Mains and Feeders, Motor Control Center Mains, Large Motor Branch Circuits and Circuit Breaker Protection Applications
Features
- Current limiting reduces short circuit damage to systems and equipment and reduced downtime
- Easily coordinated with other system components
- 10 s minimum time delay at 500% of rating eliminates needless downtime caused by heavy starting currents of large motors and other inductive loads
- Selective coordination KLLU fuses co-ordinate well with other class L fuses and with all current limiting Littelfuse fuses rated 600 A or less
- Reduced downtime
- KLLU fuse time current characteristics closely match typical time current curves of circuit breakers
- Although fuse/circuit breaker systems can seldom be 100 percent coordinated , KLLU Series fuses permit use of a wider range of breaker setting than fast-acting class L fuses
- Excellent protection for a single breaker or a group of breakers
- 200 kA at 600 VAC, 20 kA at 300 VDC interrupting rating
