Bussmann Series BB3P100M9
EATON BB3P100M9 3-Phase 9-Pin Modular Combination Busbar With Assembled End Cap, For Use With PV Series Class J/CC/Supplemental Non-Indicating Fuse, 600 V AC/DC, 100 A
Bussmann Series BB3P100M9
EATON BB3P100M9 3-Phase 9-Pin Modular Combination Busbar With Assembled End Cap, For Use With PV Series Class J/CC/Supplemental Non-Indicating Fuse, 600 V AC/DC, 100 ANon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Combination Busbar, 3-Phase 9-Pin Modular, For Use With: PV Series Class J/CC/Supplemental Non-Indicating Fuse, 600 V AC/DC, 100 A, 159 mm L
Attributes
Documents
Applications
Specifications
Features
Attributes
Country of OriginDE
Dimensions159 mm L
ManufacturerEaton
Suitable For Use WithPV Series Class J/CC/Supplemental Non-Indicating Fuse
Type / Style3-Phase 9-Pin Modular
Applications
Electrical Assemblies, Panels and EOEMs Applications
Specifications
600 V AC/DC, 100 A
Features
- Flexible cut to length solutions without compromising on the product's finger safe features
- 100 kA short circuit current rating when protected by a 200 A class J fuse
- 3 ph bus bars rated to 600 VAC/VDC and 100 A in end-fed configuration
- Power feed terminals for 3 ph systems
