Cutler-Hammer Series 1MP4206RRLB
EATON 1MP4206RRLB Group Metering Meter Pack With Horn Bypass, 200 A Self-Contained Socket, Underground Feed, 120/240 V AC, 600 A Bus
Cutler-Hammer Series 1MP4206RRLB
EATON 1MP4206RRLB Group Metering Meter Pack With Horn Bypass, 200 A Self-Contained Socket, Underground Feed, 120/240 V AC, 600 A BusNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Meter Pack, Group Metering, Self-Contained Socket, Underground Feed, 120/240 V AC, 600 A Bus, 200 A Socket, 4 Meter Sockets, 1 ph, Ringless Socket Cover Style, 5 Socket Jaws, Bolt-On/CCV2_X/CCVH2_X/CVS2_XMM/CV2_XMM/CVH2_XMM/MN/WI/IA/MI Breaker, 7.01 in L x 25.5 in W x 42.69 in H Dimensions
Attributes
Documents
Applications
Features
Warranty
Attributes
Amps200 A
Breaker TypeBolt-On/CCV2_X/CCVH2_X/CVS2_XMM/CV2_XMM/CVH2_XMM/MN/WI/IA/MI
Country of OriginUS
Feed TypeUnderground
Height42.69 in
Length7.01 in
ManufacturerEaton
MaterialSteel
NEMA RatingNEMA 3R
Number of Gangs4
Package TypeEACH
Phase1
Voltage600 VAC
Width25.5 in
Documents
Applications
Electrical Assemblies, Panels and OEMs Applications
Features
- Units are self-contained (main terminal box included) for installations requiring up to six meter socket positions in a single enclosure
- Units are not gangable with any other metering device
- Series rating up to 100 kAIC
- Bondable neutral
- Provision for 2-pole breaker
- Underground incoming feed
- Aluminum bus housing
Warranty
1 year
