Cutler-Hammer Series KT3150T
EATON KT3150T Type KT Thermal Magnetic Breaker Trip Unit, 3 Poles, 150 A, DK/KD/KDB/HKD/HKDDC/HKDB/KDC/CKD/CHKD/KG Frame, For Use With C Series Molded Case Circuit Breaker
Cutler-Hammer Series KT3150T
EATON KT3150T Type KT Thermal Magnetic Breaker Trip Unit, 3 Poles, 150 A, DK/KD/KDB/HKD/HKDDC/HKDB/KDC/CKD/CHKD/KG Frame, For Use With C Series Molded Case Circuit BreakerNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Breaker Trip Unit, Type KT Thermal Magnetic, 3 Pole, 150 A, DK/KD/KDB/HKD/HKDDC/HKDB/KDC/CKD/CHKD/KG Breaker Frame, For Use With: C Series Molded Case Circuit Breaker, 7 in L x 5.4 in W x 4.2 in H
Attributes
Documents
Applications
Features
Attributes
Connection TypeLoad Lug
Country of OriginDO
Dimensions7 in L x 5.4 in W x 4.2 in H
FrameED
Frequency Rating50/60 Hz
Interrupt Rating10 kA
ManufacturerEaton
Mounting TypePanel
Number of Poles3
Phase1
Size of Wire10 to 1/0 AWG
Suitable For Use WithC Series Molded Case Circuit Breaker
Temperature Rating40 deg C
Trip TypeThermal/Magnetic
TypeType KT Thermal Magnetic
Type / StyleType KT Thermal Magnetic
Applications
Commercial, Institutional Buildings, Structures and Circuit Protection Applications
Features
- For use with standard or high or ultra high interrupting frames
- Interchangeable trip units with long time and instantaneous (LI) trip functions
- Bolt-on mounting
- 65 kA at 240 VAC, 35 kA at 480 VAC, 25 kA at 600 VAC interrupt rating
- Adjustable IR switch allows for continuous current settings and eliminates the need for rating plug
- Long delay i2t setting with variable trip times
- Long, short, instantaneous and ground fault protection
