Cutler-Hammer Series BR230ST
EATON BR230ST Common Shunt Trip, 120/240 V AC, Plug-On Mount
Cutler-Hammer Series BR230ST
EATON BR230ST Common Shunt Trip, 120/240 V AC, Plug-On MountNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #BR230ST
Werner Part #541840
UPC786676000239
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #BR230ST
Werner Part #541840
UPC786676000239
Product Description
EATON Shunt Trip, Common, 120/240 V AC, Plug-On Mount, For Use With: Type BR Loadcenter and BR230 2-Pole 30 A Circuit Breaker, 4-1/2 in L x 4-1/4 in W x 4 in H
Attributes
Documents
Applications
Features
Attributes
ColorWhite
Country of OriginDO
Dimensions4-1/2 in L x 4-1/4 in W x 4 in H
Enclosure TypeNEMA 4X/IP69K
FinishConformal Coating
Frequency Rating60 Hz
ManufacturerEaton
Mounting TypeWall
Package Height4 in
Package Length4.5 in
Package TypeEACH
Package Weight1 lb
Package Width4.25 in
Phase3
SeriesSB5000 Series
Suitable For Use WithType BR Loadcenter and BR230 2-Pole 30 A Circuit Breaker
Temperature Rating-31 to 104 deg F
Trip Range20
TypeCommon
Type / StyleCommon
Voltage120/240 VAC
Documents
Applications
Conventional Energy Generation, Renewable Energy and Alternative Energy Generation, Marine Vessels and Equipment and Circuit Protection Applications
Features
- Available in 1 in thermal magnetic
- and AF/GF designs
- Short-body design maximizes your space inside the loadcenter
- creating additional wire-way and gutter space for ease of installation
- Easy to read trip codes through improved LEDs and a clear test button increases your troubleshooting efficiency
- Improved AFCI and GFCI algorithms significantly reduce nuisance tripping
- resulting in less call backs
