Pos-E-Kon MS216B
Pos-E-Kon MS216B B Series Standard Terminal Insert, 16 Positions, 20 to 14 AWG Wire, Male Screw Connection, Glass Filled Thermoplastic
Pos-E-Kon MS216B
Pos-E-Kon MS216B B Series Standard Terminal Insert, 16 Positions, 20 to 14 AWG Wire, Male Screw Connection, Glass Filled ThermoplasticOut of Stockmore info
|
BrandPos-E-Kon
MFG #MS216B
Werner Part #64908
UPC786210118468
Out of Stockmore info
|
BrandPos-E-Kon
MFG #MS216B
Werner Part #64908
UPC786210118468
Product Description
Pos-E-Kon Terminal Insert, Standard, Series: B Series, 16 Positions, 20 to 14 AWG Wire, Male Screw Connection, For Use With: B Series Connector, -40 to 257 deg F, Specifications: 16 A, 600 V AC, Glass Filled Thermoplastic
Attributes
Documents
Applications
Features
Specifications
Attributes
Connection TypeMale Screw
Country of OriginDE
ManufacturerABB
MaterialGlass Filled Thermoplastic
Number of Positions16
SeriesB Series
Size of Wire20 to 14 AWG
Suitable For Use WithB Series Connector
Temperature Rating-40 to 257 deg F
TypeStandard
Type / StyleSTANDARD
Documents
Applications
For panel base applications
Features
- 16-contact with ground
- Integral screw terminal contacts that provide for easy terminal wiring and fast assembly
- Allows single access direction panel build wiring and easy terminal ID for service and testing
- Standard wire protection saddles prevent cutting of strands during assembly
- Standard size screw terminal
- Use small blade screwdriver to push wire entry tab in for easy contact removal
Specifications
16 A, 600 V AC
