nVent ILSCO LDB-22-350
ILSCO Snapbloc LDB-22-350 Type LDB Dual Rated Mechanical Power Distribution Block With Clear Cover, 600 V AC, 620 A, 1 Pole, 6 AWG to 350 kcmil Wire, Aluminum Alloy
nVent ILSCO LDB-22-350
ILSCO Snapbloc LDB-22-350 Type LDB Dual Rated Mechanical Power Distribution Block With Clear Cover, 600 V AC, 620 A, 1 Pole, 6 AWG to 350 kcmil Wire, Aluminum AlloyNon-stock product. Available to order - lead time may vary.
BrandnVent ILSCO
MFG #LDB-22-350
Werner Part #40789
UPC783669595154
Non-stock product. Available to order - lead time may vary.
BrandnVent ILSCO
MFG #LDB-22-350
Werner Part #40789
UPC783669595154
Product Description
ILSCO Snapbloc Power Distribution Block, Type LDB Dual Rated Mechanical, 600 V AC, 620 A, 1 Pole, 2 Primary Connections/Pole, 2 Secondary Connection/Pole, 6 AWG to 350 kcmil Wire, 10 kA Short Circuit, Aluminum Alloy, Electro-Plated Tin, Blue, 3 in L x 5-1/2 in W x 3-7/16 in H Dimensions
Attributes
Documents
Applications
Features
Attributes
ColorBlue
Country of OriginMX
Dimensions3 in L x 5-1/2 in W x 3-7/16 in H
FinishElectro-Plated Tin
ManufacturerECM Industries
MaterialAluminum Alloy
Number of Poles1
Package Height3 in
Package Length4.75 IN
Package TypeEACH
Package Weight1.03 lb
Package Width3.57 in
Primary Connection/Pole2
Secondary Connection/Pole2
Short Circuit Current Rating10 kA
Size of Wire6 AWG to 350 kcmil
Suitable For Use WithType DS Switch and Enclosed Circuit Breaker
TypeType LDB Dual Rated Mechanical
Type / StyleType LDB Dual Rated Mechanical
Voltage600 VAC
Applications
Tap Connector Applications
Features
- Modular design
- Easy to assemble
- Multiple conductor capability
- Simplifies stocking, combines any number of blocks with multiple conductor ranges into the specific configuration required for the job
- Unique locking feature allows individual blocks to be combined quickly without special tools
- Ensures reliability
- Permits visual inspection
- Aluminum connector
- 3/8 in hex primary, 3/8 in hex secondary
- (2) box lug primary, (2) box lug secondary
- 6 AWG to 350 kcmil primary and secondary wire
- Lexan insulating base
- UL assigned short circuit current rating
- Manufactured from high strength 6061-T6 aluminum alloy
- LDA, LDAU are added to LDB, LDBU to obtain a multi-pole block
- Convert LDA,LDAU to LDB, LDBU by adding LDS-1 side plate
