Lithonia Lighting L7XLED T24 U
Lithonia Lighting L7XLED T24 U L7XLED T24 New Construction Downlight Housing, Insulated/Non-Insulated Insulation, 120 VAC, 7 in Ceiling Opening, Aluminum Housing
Lithonia Lighting L7XLED T24 U
Lithonia Lighting L7XLED T24 U L7XLED T24 New Construction Downlight Housing, Insulated/Non-Insulated Insulation, 120 VAC, 7 in Ceiling Opening, Aluminum HousingNon-stock product. Available to order - lead time may vary.
BrandLithonia Lighting
MFG #L7XLED T24 U
Werner Part #4057726
UPC745977951916
Non-stock product. Available to order - lead time may vary.
BrandLithonia Lighting
MFG #L7XLED T24 U
Werner Part #4057726
UPC745977951916
Product Description
Lithonia Lighting, L7XLED T24 U, Downlight Housing, New Construction, Series: L7XLED T24, 120 VAC, 7 in Ceiling Opening, 1 Lamps, Insulated/Non-Insulated Insulation, Recessed Mounting, For Use With: REALITY ENERGY STAR (ESL) Open Narrow Flange LED Module/P Series Open and Baffle Wide Flange LED Modules, 6 in Diameter, 16.2 in Height, 8.1 in Width, Aluminum Housing Material, Gray
Attributes
Documents
Applications
Warranty
Features
Attributes
Ceiling Opening7 in
ColorGray
Country of OriginMX
Diameter6 in
Dimensions12.1 in L x 2.5 in W x 7.6 in H
Fixture Wattage0.78 W
Height16.2 in
Housing MaterialAluminum
Insulation TypeInsulated/Non-Insulated
Lamp TypeLED
Lamp Wattage1.31/1.74 W
Light ColorWhite
ManufacturerAcuity Brands
Mounting TypeSurface
Number of Lamps1
Power SourceAC Powered Battery
SeriesL7XLED T24
Suitable For Use WithREALITY ENERGY STAR (ESL) Open Narrow Flange LED Module/P Series Open and Baffle Wide Flange LED Modules
TypeNew Construction
Voltage Rating120 V AC
Documents
Applications
Commercial and Residential Applications
Warranty
1 Year
Features
- Recessed housing rated IC or Non-IC
- Galvanized steel junction box (4) built-in Romex clamps
- Five 1/2 in and (2) 3/4 in nominal knockouts with slots for pryout
- Rated for through branch wiring, rated for 90 deg C
- Maximum 4 (2 in, 2 out) 12 AWG conductors
- Ground wire provided
- Removable J-box doors for easy access
- Two side mounted torsion springs on the trim and 2 receiving brackets in the can ensure a consistently tight fit with the ceiling
- Quick disconnect provided for power connection to the LED modules
- Paint overspray masked by disposable disconnect plug
- Housing and LED module combination is IC rated and thermally protected
- For new construction
- 15 in L, ceiling/recessed mounting
- Approved for all ceiling and wiring types
- Approved for direct burial in insulation
- Airtight standard
- Tested to meet current energy codes
- Aluminum foam gasketed housing with galvanized steel pan
- Galvanized bar hangers span up to 24 in outer circumference and feature built-in nailer and integral T-bar clips
- Two locking screws hold fixture in position
