Hubbell Wiring Device - Kellems L520C
Hubbell Wiring Device-Kellems Hubbell-PRO Twist-Lock L520C Female Grounding Standard Cord Mount Locking Connector, 125 V AC, 20 A, 2 Poles, 3 Wires, Black/White
Hubbell Wiring Device - Kellems L520C
Hubbell Wiring Device-Kellems Hubbell-PRO Twist-Lock L520C Female Grounding Standard Cord Mount Locking Connector, 125 V AC, 20 A, 2 Poles, 3 Wires, Black/WhiteIn Stock: 378more info
|
BrandHubbell Wiring Device - Kellems
MFG #L520C
Werner Part #1522437
UPC783585835761
In Stock: 378more info
|
BrandHubbell Wiring Device - Kellems
MFG #L520C
Werner Part #1522437
UPC783585835761
Product Description
Hubbell Wiring Device-Kellems Hubbell-PRO Twist-Lock Locking Connector, Female Grounding Standard Cord Mount, 125 V AC, 20 A, 2 Pole, 3 Wires, L5-15R NEMA Rating, Commercial/Industrial Grade, 0.385 to 1.15 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Composite, Black/White
Attributes
Documents
Applications
Features
Specifications
Attributes
ColorBlack/White
Country of OriginCN
GradeCommercial/Industrial
GTIN00783585835761
ManufacturerHubbell
MaterialComposite
NEMA RatingL5-15R
Number of Poles2
Number of Wires3
Package TypeEACH
SeriesFemale Grounding Standard
Temperature Rating-40 to 75 deg C
Terminal TypeScrew
TypeFemale Grounding Standard Cord Mount
Type / StyleFemale Grounding Standard
Voltage Rating125 V AC
Documents
Applications
Heavy Duty Industrial Applications
Features
- Supertough nylon body
- Visible NEMA ratings
- Captive assembly screws
- Impact modified nylon blade/contact holder
- High performance copper alloy contacts/blade
- Withstands 3500 VAC per UL 498 dielectric voltage
- Minimum 4.8 times rated current for 100 cycles overload
- Terminals identified in accordance with UL 498
- 18 to 8 AWG flexible cord terminal accommodation
- Ratings and NEMA identification are permanently marked on device
- Cord mounted
- Insulated body
- Indoor dry unless protected by additional means
- 14 to 12 AWG conductor size
- Standard sized product
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|CSA Certified|UL 498|NEMA WD1/WD5
