Hubbell Wiring Device - Kellems HBLDS3NK

Hubbell Wiring Device-Kellems Circuit-Lock HBLDS3NK 2-Position Industrial Grade Labelless Non-Metallic Standard Unfused Disconnect Switch, 600 V, 30 A, 15 hp, 2-Position Contact, 3 Poles
Hubbell Wiring Device-Kellems Circuit-Lock HBLDS3NK 2-Position Industrial Grade Labelless Non-Metallic Standard Unfused Disconnect Switch, 600 V, 30 A, 15 hp, 2-Position Contact, 3 Poles

Hubbell Wiring Device - Kellems HBLDS3NK

Hubbell Wiring Device-Kellems Circuit-Lock HBLDS3NK 2-Position Industrial Grade Labelless Non-Metallic Standard Unfused Disconnect Switch, 600 V, 30 A, 15 hp, 2-Position Contact, 3 Poles
Out of Stockmore info

BrandHubbell Wiring Device - Kellems

MFG #HBLDS3NK

Werner Part #3832383

UPC783585841014

Out of Stockmore info

BrandHubbell Wiring Device - Kellems

MFG #HBLDS3NK

Werner Part #3832383

UPC783585841014

Product Description

Hubbell Wiring Device-Kellems Circuit-Lock, HBLDS3NK, Disconnect Switch, 2-Position Industrial Grade Labelless Non-Metallic Standard Unfused, 600 V, 30 A, 15 hp, 3 ph, 60 Hz Frequency, 3 Pole, 65 kA Short Circuit, 2-Position Contact Form, Lever Actuator, NEMA 4X Enclosure, Foot Mounting, Screw Terminal, -40 to 75 deg C, 8.5 x 6 x 4.12 in Dimensions, Composite, Gray
Attributes
Actuator TypeLever Operated
ColorGray
Country of OriginPL
Dimensions8.5 x 6 x 4.12 in
Enclosure TypeNEMA 4X
Frequency Rating60 Hz
Horsepower15 hp
ManufacturerHubbell
MaterialComposite
Number of Poles3
Package Height4.6 IN
Package Length8.5 IN
Package TypeEACH
Package Weight1.26 lb
Package Width5.6 in
Phase3
Short Circuit Current Rating65 kA
Suitable For Use WithFusible NEMA 1 TH3363 Disconnect Safety Switch
Temperature Rating-40 to 75 deg C
Terminal TypeScrew
Type2-Position Industrial Grade Labelless Non-Metallic Standard Unfused
Type / StyleIndustrial Grade Labelless Non-Metallic Standard Unfused
Voltage600 VAC
