Hubbell Wiring Device - Kellems HBLDS6RC
Hubbell Wiring Device-Kellems Circuit-Lock HBLDS6RC Non-Metallic Standard UnFusible Replacement Cover, For Use With HBLDS6 Series 30 A Unfused Disconnect Switch, -40 to 67 deg C Continuous Temperature, NEMA 4X, 2-Position, Terminal Screw, Non-Metallic Enclosure
Hubbell Wiring Device - Kellems HBLDS6RC
Hubbell Wiring Device-Kellems Circuit-Lock HBLDS6RC Non-Metallic Standard UnFusible Replacement Cover, For Use With HBLDS6 Series 30 A Unfused Disconnect Switch, -40 to 67 deg C Continuous Temperature, NEMA 4X, 2-Position, Terminal Screw, Non-Metallic EnclosureNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Hubbell Wiring Device-Kellems Circuit-Lock, HBLDS6RC, Replacement Cover, Non-Metallic Standard UnFusible, For Use With: HBLDS6 Series 30 A Unfused Disconnect Switch, Specifications: -40 to 67 deg C Continuous Temperature, NEMA 4X, 2-Position, Terminal Screw, Non-Metallic Enclosure, Composite, Gray, 9.96 in L x 6.86 in W x 2.437 in H Dimensions
Attributes
Documents
Applications
Specifications
Warranty
Features
Attributes
ColorGray
Connection TypeBox
Country of OriginPR
Dimensions9.96 in L x 6.86 in W x 2.437 in H
Interrupt Rating10 kA
ManufacturerHubbell
MaterialComposite
Mounting TypePlug-In
Number of Poles1
Package TypeEACH
Phase1
Size of Wire14 to 10 AWG
Suitable For Use WithHBLDS6 Series 30 A Unfused Disconnect Switch
Trip TypeLI/Non-Interchangeable Thermal Magnetic
TypeNon-Metallic Standard UnFusible
Type / StyleNon-Metallic Standard UnFusible
Documents
Applications
Industrial and Indoor Applications
Specifications
-40 to 67 deg C Continuous Temperature, NEMA 4X, 2-Position, Terminal Screw, Non-Metallic Enclosure
Warranty
1 Year
Features
- Highly visible red handle which meets OSHA lockout/tagout capabilities
- -40 to 67 deg C without impact
- Stainless steel hardware for corrosion resistance
- Certified by NSF for hygiene in food processing applications
- Reversible interior accommodates top or bottom conduit opening
- Type 4X enclosure is molded of rugged Valox
- Constructed from corrosion and impact resistant UV stabilized non-metallic material
- IP69k and Type 4X, 12K water ingress protection
